Western Digital WD9001BKHG 900GB 10K SAS 2.5" Hard Drive

Western Digital Part #/MPN: WD9001BKHG

DiscTech Item #: WDC-WD9001BKHG-BN-5Y

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Enterprise Grade

Capacity: 900GB

Speed: 10,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: 204

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps

On-Board Cache: 32MB

Western Digital WD XE WD9001BKHG 900GB 10K SAS 2.5" Hard Drive- Brand New

Western Digital WD9001BKHG WD XE 900GB 10K SAS 2.5 Hard Drive-Brand New

WD S25 SAS hard drives provide up to 900 GB of high performance storage suitable for both enterprise server and enterprise storage applications. The ultra-fast 6 Gb/s SAS interface enables optimum data reliability, availability, and scalability. In an environment where space and power are limited, the WD S25 drives are an effective solution for high performance computing solutions such as power-constrained data centers, database transaction processing, and rack, tower, and blade servers.

PNs: WD9001BKHG-02D22V1


This drive is compatible with any server that accepts small form factor (SFF) SAS hard drives

Model number WD9001BKHG
Model Name S25
Formatted Capacity 900 Gbytes
Rotational Speed 10,000 rpm
Default Buffer (cache) Size 32 Mbytes
Sectors per drive1,758,174,768
ROHS CompliantYes
External (I/O) Transfer Rate (max) 204 MBytes/sec
Form Factor(width) 2.75-inch
Form Factor(height) .59-inch
Height 15 mm
Width 69.85 mm
Length 100 mm
Weight 0.23 kg
Power Dissipation Read/Write .7.80 watts
Max Operating Shock (2-msec) 65 Gs
Max Nonoperating Shock (2-msec) 300 Gs
Operating Vibration (max) .5 Gs
Nonoperating Vibration (max) 2.4 Gs
Operating Temperature (max) 55 deg C
Operating Temperature (min) 5 deg C
Nonoperating Temperature (max) 70 deg C
Nonoperating Temperature (min) -40 deg C
Nonrecoverable Read Errors 1 per 10^16 bits read
Supports S.M.A.R.T.Yes

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: WD9001BKHG-02D22V1

Weight: 1 lb

Warranty: 5 Year Manufacturer

Brand New

Condition Levels Explained

The product is brand new.

5 Year Manufacturer Warranty

Product Warranties Explained

The product has a manufacturer warranty for the time period specified.
