NVIDIA Quadro P5000 16GB GDDR5X 00MKC 900-5G413-0100-000 PCIe 3.0 x16 DVI Graphics Card

NVIDIA Part #/MPN: P5000

DiscTech Item #: NVI-P5000-BN-OE

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.


Interface Types: PCIe, DVI-D, DisplayPort, VGA

Electrical Interface: PCIe - v3.0 - 16GBps

On-Board Cache: 16GB

Wattage/VA: 180W

Resolution: 7680x4320

NVIDIA Quadro P5000 16GB GDDR5X 00MKC 900-5G413-0100-000 PCIe 3.0 x16 DVI Graphics Card - Brand New

NVIDIA Quadro P5000 Pascal Series 16GB GDDR5X PCIe 3.0 x16 256-bit DVI-D 180W Graphics / Video Card GPU - Brand New



  • Four DisplayPort 1.4 Connectors
  • DisplayPort with Audio
  • VGA Support
  • 3D Stereo Support with Stereo Connector
  • NVIDIA GPUDirect™ Support
  • Quadro Sync II2 Compatibility
  • NVIDIA nView® Desktop Management Software Compatibility
  • HDCP 2.2 Support
  • NVIDIA Mosaic

The NVIDIA Quadro P5000 workstation graphics card, powered by NVIDIA Pascal™ GPU technology, features 16 GB memory capacity and enables an expansive visual workspace with quad display outputs. Work with larger models, complex visual effects and simulations, larger rendering tasks, and more life-like VR experiences in your workflow today and be well prepared for the challenges of tomorrow.
Quadro cards are certified with a broad range of sophisticated professional applications, tested by leading workstation manufacturers, and backed by a global team of support specialists. This gives you the peace of mind to focus on doing your best work. Whether you’re developing revolutionary products or telling spectacularly vivid visual stories, Quadro gives you the performance to do it brilliantly.

The P5000 features 2560 CUDA cores and 16GB of GDDR5 memory, which allows it to deliver high levels of performance for demanding tasks such as 3D modeling, animation, and virtual reality. It also supports NVIDIA's Quadro Sync II technology, which allows multiple P5000 cards to be synchronized for use in large-scale visualization systems.

The P5000 is typically used in professional workstations for applications such as CAD/CAM, architecture, engineering, and scientific computing. It is also suitable for use in high-end gaming systems, although it is primarily intended for professional use.

Alt. PNs : 699-5G413-0500-100 / 900-5G413-0100-000 / 00MKC / 000MKC / 490-BDNN / VCQP5000-PB


The NVIDIA P5000 graphics card is compatible with a variety of workstation-class systems that meet the card's system requirements, including but not limited to:

HP Z8 WorkstationHP Z6 WorkstationHP Z4 Workstation
Dell Precision 5820 TowerDell Precision 7820 TowerDell Precision 7920 Tower
Lenovo ThinkStation P520Lenovo ThinkStation P720Lenovo ThinkStation P920
Fujitsu Celsius M770Fujitsu Celsius R970

GPU Memory16 GB GDDR5X
Memory Interface256-bit
Memory BandwidthUp to 288 GB/s
NVIDIA CUDA® Cores2560
System InterfacePCI Express 3.0 x16
Max Power Consumption150 W
Thermal SolutionActive
Form Factor4.4” H × 10.5” L, Dual Slot, Full Height
Display Connectors4x DP 1.4 + DVI-D DL
Max Simultaneous Displays4 direct, 4 DP 1.4 Multi-Stream
Max DP 1.4 Resolution7680 x 4320 @ 30 Hz
Max DVI-D DL Resolution2560 × 1600 @ 60 Hz
Graphics APIsShader Model 5.1
OpenGL 4.5
DirectX 12.0
Vulkan 1.0
Compute APIsCUDA, DirectCompute, OpenCL™

Click here to view the manufacturer's item description/brochure

Alternate MPNs: 699-5G413-0500-100 900-5G413-0100-000 00MKC 000MKC 490-BDNN VCQP5000-PB

Weight: 3 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
