Dell 0FYFW / Toshiba PX05SRB192Y 1.92TB SAS SSD ME4

Toshiba PX05SRB192Y SDFAM81DAB01 0FYFW 00FYFW 1.92TB SAS Solid State Drive ME4 Image 1 imageToshiba PX05SRB192Y SDFAM81DAB01 0FYFW 00FYFW 1.92TB SAS Solid State Drive ME4 Image 2 imageToshiba PX05SRB192Y SDFAM81DAB01 0FYFW 00FYFW 1.92TB SAS Solid State Drive ME4 Image 3 imageToshiba PX05SRB192Y SDFAM81DAB01 0FYFW 00FYFW 1.92TB SAS Solid State Drive ME4 Image 4 image
  • Brand New
    Condition Levels Explained

    The product is brand new.

  • In Stock:1
    Need more?
    Stock Levels

    This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.

  • 1 Year DiscTechWarranty
    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty

$749.00

Capacity:1.92TB
Speed:Solid State
Interface Types:SAS
Form Factor:2.5" SFF Server Drive
SSD Endurance DWPD:Enterprise Read Intensive / RI
Electrical Interface:SAS-3 12Gbps
Click to see more 1.92TB SAS Solid State Drives

Description

Dell 0FYFW / Toshiba PX05SRB192Y PX05S Series 1.92TB 2.5" 12Gbps MLC SAS SSD ME4 - Brand New

Dell 0FYFW / Toshiba PX05SRB192Y 1.92TB / 1920GB 2.5" 12.0 Gb/s Multi Level Cell Read Intensive 1-DWPD SAS / Serial Attached SCSI MU SSD / Solid State Disk Drive - Brand New

DPN : 8V7C5 08V7C5

Enterprise Read Intensive SSD

The PX05S Series is our 4th generation enterprise SAS SSD leveraging the highly successful PX04S Series. The PX05SR Series is designed for read-intensive application workloads including web servers, data warehousing, media streaming and VOD and offers large capacities up to 3.84TB with 12.0 Gbit/s SAS interface.

The series’ 270K IOPS sustained random read performance and 1,400 - 1,800 MB/s sequential read performance helps read-intensive application workloads to realize superior results and assists organizations in minimizing total cost of ownership while maintaining high performance, reliability and endurance for maximum scalability.

Optimized for applications demanding 1 Drive Writes Per Day (DWPD), the family is equipped with unique customer-tunable feature allowing optimization for maximum performance or power efficiency. Additional features include power-loss protection and full data path protection. Each model supports pin-3 power disable for improved enclosure services control over storage media. Self-encrypting drive options with instant secure erase are also available.

KEY FEATURES

  • 270K IOPS random read (4K) performance
  • 1 DWOD wutg 100% Random Write Workload
  • Pin-3 Disable Support
  • Power-Loss_Protection and End-to-end data protection including T10 DIF
  • Sanitize Instant Erase (SIE) option
  • Self-encrypting drive (SED)
  • Self-encrypting drive (SED), FIPS Certified

APPLICATIONS

  • Data Warehousing
  • Web Servers
  • Video on Demand
  • Streaming media

DPN: 8V7C5/ 08V7C5

* SIE: Sanitize Device Feature set is the standard prescribed by T10 (SAS) committee of American National Standards Association(ANSI), which makes it possible to invalidate the data recorded on the NAND flash memory at a blink.

* SED drive is conformed to TCG enterprise SSC.

* SED and FIPS 140-2 Validated drives are not available in all models or countries. May require TCG-Compliant host or controller support.

Compatibility

This drive is designed to work in the Dell ME4 series arrays. This includes the ME4012, ME4024, ME4084, ME412, ME424, ME484. It will also work in the Dell PowerEdge and PowerVault systems.

Specifications

Toshiba Enterprise Read Intensive SSD
Model NumberPX05SRB192Y
Capacity1.92TB / 1920 GB
InterfaceSAS-3.0
Interface Speed12.0 Gbit/s , 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit/s
Memory TypeMLC
Sustained 64KiB Sequential Read1,400 MiB/s
Sustained 64KiB Sequential Write750 MiB/s
Sustained 4KiB Random Read270,000 IOPS
Sustained 4KiB Random Write25,000 IOPS
MTTF2,000,000 hours
DWPD1
Supply Voltage5 V ±7 % , 12 V ±7 %
Power Consumption (Ready)3.2 W Typ.
Height15.0 mm +0 , -0.5 mm
Width69.85 ±0.25 mm
Length100.45 mm Max.
Weight150 g Max.
Temperature ( Operating )0 to 55 °C
Relative Humidity ( Operating )5 to 95 % R.H.
Vibration ( Operating )21.27 m/s { 2.17 Grms } ( 5 to 800 Hz )
Shock ( Operating )9,800 m/s { 1,000 G } ( 0.5 ms duration )
Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: SDFAM81DAB01 0FYFW 00FYFW

Weight: 0.5 lb

Warranty: 1 Year DiscTech

Condition

Brand New

Warranty

1 Year DiscTech Warranty
