Dell Compellent 8JYJK / HGST HUSMH8040BSS200 / 0B32017 400GB 2.5" SAS WI Enterprise Plus SSD

Hitachi Part #/MPN: HUSMH8040BSS200

DiscTech Item #: HIT-HUSMH8040BSS200-BN-OE-DEC


Enterprise Grade

Capacity: 400GB

Speed: Solid State Memory

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: 1100/765

Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps


SSD Endurance DWPD: Enterprise Write Intensive

Compatible Systems: Dell Compellent SCv2000 SCv2020 SC200 SC120 SC100

Dell Compellent 08JYJK / 8JYJK / HGST HUSMH8040BSS200 / 0B32017 400GB 2.5-Inch SFF 12Gbps MLC Write Intensive SE SAS Enterprise Plus Solid State Drive - Brand New

Dell Compellent 08JYJK / 8JYJK / HGST / Hitachi Ultrastar SSD800MMH.B 0B32017 / HUSMH8040BSS200 400GB 2.5" SFF / Small Form Factor 12.0 Gb/s MLC / Multi-Level Cell NAND Write Intensive 25-DWPD / Drive Writes Per Day SE / Secure Erase SAS / Serial Attached SCSI Enterprise Plus SSD / Solid State Drive - Brand New

Ultrastar SSD800MMH.B

Maximum Performance, Reliability and Endurance
The Ultrastar SSD800MH.B delivers high sequential throughput, up to 1100MB/s read and 765MB/s write (12Gb/s SAS). It also delivers up to 130,000 read and 110,000 write IOPS, reaching speeds >100 times faster than HDDs and double the speed of current 6Gb/s SSDs, allowing rapid access to “hot” enterprise data for improved productivity and operational efficiency. The Ultrastar SSD800MH.B family offers significant value in terms of IOPS per Watt, while reducing total cost of ownership (TCO) through low power consumption, efficient cooling and reduced space requirements.
The Ultrastar SSD800MH.B family combines enterprise-grade MLC NAND Flash memory, advanced endurance management firmware and power loss data management techniques to extend reliability, endurance and sustained performance over the life of the SSD. The Ultrastar SSD800MH.B family achieves an extraordinary 0.35% annual failure rate (AFR) or 2.5 million hour meantime-between-failure (MTBF). The 800GB capacity model endures up to 36.5 Petabytes (PB) of random writes over the life of the drive—the equivalent of writing 20 Terabytes (TB) per day for five years

HGST Enterprise Storage ExperienceHGST leverages decades of proven enterprise storage expertise in Serial Attached SCSI (SAS) design, reliability, firmware, customer qualification and system integration to the Ultrastar® SSD800MH.B solid-state drive (SSD) family. The synergistic relationship between HGST’s throughput-enhancing SSDs and traditional HDDs provides cost effective, end-to-end enterprise-class storage solutions, delivering reliability, compatibility, capacity, cost and system performance. This combination makes HGST a leading SSD/HDD provider with the experience and technology needed to meet escalating reliability, endurance and performance in the most demanding enterprise environments.

HGST Quality and Service
HGST’s Ultrastar SSD800MH.B family extends the company’s long-standing tradition of performance and reliability leadership. A balanced combination of new and proven technologies enables high reliability and availability to customer data. HGST drives are backed by an array of technical support and services, which may include customer and integration assistance. HGST is dedicated to providing a complete portfolio of SSD/HDD solutions to satisfy today’s monumental computing needs.


  • MLC NAND Flash for ultra-high performance and endurance
  • Mainstream endurance 25DW/D for 5 years
  • Best IOPS/Watt for reduced TCO
  • 12Gb/s SAS interface for maximum throughput
  • Advanced power loss data management technology
  • Self-encrypting models conform to TCG’s Enterprise specification

Applications / Environments

  • Ultra-high performance tier-0 enterprise storage
  • Enterprise-class servers and high performance computing
  • Space and/or power constrained environments
  • Online Transaction Processing (OLTP)
  • Financial and e-commerce
  • Database analytics



This 3.5" SAS / SATA Drive is compatible with the following Dell SC Compellent systems supporting 3.5" hot swappable disks:

Dell Compellent SC120Dell Compellent SC220Dell Compellent SCv2020Dell Compellent SC4020
Dell Compellent SC5020Dell Compellent SC5020fDell Compellent SC420Dell Compellent SCv3020

HGST Ultrastar SSD800MMH.B
Model NumberHUSMH8040BSS200
Alt Model Number08JYJK
Encryption levelNo Encryption, Secure Erase
InterfaceSAS 6/12Gb/s supports Wide port @ 12Gb/s
Endurance (Drive Writes per Day - DW/D)25
Endurance (max PB, Rnd write)18.3
Form Factor2.5-inch SFF
Flash Memory Technology3D Multi-Level Cell (MLC) NAND
Read Throughput (max MB/s, Seq. 128KiB)1100
Write Throughput (max MB/s, Seq. 128KiB)765
Read IOPS (max, Rnd 4KiB)130K
Write IOPS (max, Rnd 4KiB)110K
Error Rate (non-recoverable, bits read)1 in 10e17
MTBF (M hours)2.5
Annualized Failure Rate (AFR)0.35%
Availability (hrs/day x days/week)24x7
Requirement (+/- 5%)+5 VDC, +12VDC
Operating Modes (W, typical)
  • 9
  • 11
Idle (W, max)2.2
Physical Size
z-height (mm)15
Dimensions (width x depth, mm)70.1 x 100.6
Weight (max, g)187
Operating Temperature0º to 70º C
Non-operating Temperature-40º to 80º C
Shock (half-sine wave, G)1000G (0.5ms), 500G (2ms)
Vibration, random (G RMS, 5 to 700Hz)2.16 (XYZ)

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 08JYJK 8JYJK 0B32017

Weight: 1 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
