Toshiba Part #/MPN: KPM5WRUG3T84
DiscTech Item #: KIO-KPM5WRUG3T84-BN-OE-DEP
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:55Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 3.84TB
Speed: Solid State Memory
Interface Types: SAS Serial Attached SCSI
Form Factor: 2.5inx15mm SFF Server Drive
Encryption/SED Supported
Sector Size: 512 / 512e
Sustained Throughput: 2097 / 1887
Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps
SSD Type: TLC
SSD Endurance DWPD: Enterprise Read Intensive
Compatible Systems: Dell 14th Gen. R640/R740, Dell 13th Gen. R730/T630, Dell 12th Gen. R720/T620
Dell Enterprise Plus KFV6V / KIOXIA Toshiba KPM5WRUG3T84 3.84TB 2.5inch 12Gbps Read Intensive 1-DWPD MLC SAS SED FIPS 140-2 SSD - Brand New
Dell Enterprise Plus KFV6V / KIOXIA Toshiba KPM5WRUG3T84 3.84TB 2.5inch 12Gbps Read Intensive 1-DWPD MLC SAS SED FIPS 140-2 SSD - Brand New
PM5-R Series - Enterprise Read Intensive SSD
PM5-R 12.0 Gbit/s enterprise SAS SSD is optimized for read intensive applications, including web services, data warehousing, media streaming and video on demand. The Series provides high levels of performance, reliability and endurance, and is designed to minimize total cost of ownership.
Featuring KIOXIA Corporation’s 64-layer BiCS FLASH™ 3D memory, this 5th generation enterprise SAS SSD offers 1 DWPD (Drive Write Per Day) with capacities up to 15.36 TB.
Key Features
- 12.0 Gbit/s SAS interface with single/dual port and MultiLink SAS™ support
- Capacities from 480 GB to 15.36 TB
- T10 Multi-Stream Write support
- Up to 385 K random read IOPS (4 KiB) in dual port mode
- 2.5 inch form factor, 15 mm Z-height
- 1 DWPD with 100 % Random Write Workload
- Power loss protection and end-to-end data protection, including T10 DIF
- Pin-3 power disable support
- Sanitize Instant Erase (SIE) option
- Self-Encrypting (SED) option
- Self-Encrypting (SED), FIPS 140-2 validated option
Key Applications
- Media streaming
- Data warehousing
- Web servers
- Video on demand (VOD)
Alt PN: 0FV3JW FV3JW 0KFV6V KFV6V
Compatibility:
This drive is compatible with any server that accepts 2.5in x 15mm (SFF) large capacity >2TB SAS drives.
| Enterprise Read Intensive SSD | |
|---|---|
| Model Number | KPM5WRUG3T84 / KFV6V |
| Basic Specifications | |
| Interface | SAS-3.0 |
| Interface Speed | 12.0 Gbit/s , 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit/s |
| Memory Type | BiCS FLASH TLC |
| Formatted Capacity | 3.84TB |
| Sustained 64KiB Sequential Read | 2097 MiB/s |
| Sustained 64KiB Sequential Write | 1887 MiB/s |
| Sustained 4KiB Random Read | 370,000 IOPS |
| Sustained 4KiB Random Write | 50,000 IOPS |
| Encryption | SED FIPS 140 |
| Reliability | |
| MTTF | 2,500,000 hours |
| DWPD | 1 |
| Power Requirements | |
| Supply Voltage | 5 V ±7 % , 12 V ±7 % |
| Power Consumption (Operating) | 3.2W Typ. |
| Dimensions | |
| Height | 15.0 mm +0 , -0.5 mm |
| Width | 69.85 ±0.25 mm |
| Length | 100.45 mm Max. |
| Weight | 130 g Max. |
| Enviromental | |
| Temperature (Operating) | 0 to 55 °C |
| Relative Humidity ( Operating ) | 5 to 95 % R.H. |
| Vibration (Operating) | 21.27 m/s {2.17 Grms} (100 to 800 Hz) |
| Shock (Operating) | 9.8 km/s {1,000 G} (0.5 msec) |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: KFV6V 0KFV6V FV3JW 0FV3JW
Weight: 0.7 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
