Dell PowerEdge R720XD Server

(0) No Reviews Yet

Dell Part #/MPN: PER720XD

DiscTech Item #: DEL-PER720XD-BN-2M


$3,999.00
$3,999.00

Interface Types: SAS Serial Attached SCSI, SATA

Form Factor: 3.5inx1.0in LFF Hard Drive

Bays/Ports/Slots: 26

U Height: 2U

Dell PowerEdge / Power Edge R720XD Server - Rackmount - Brand New

Outstanding storage capacity in a 2-socket 2U rack server.

Scale for massive data growth with the excellent storage capacity, memory density and I/O (input/output) capabilities of the Dell PowerEdge R720xd rack server.



  • Gain superb computing performance with Intel® Xeon® E5-2600 Processors and up to 24 DIMM slots.
  • Enhance storage scalability with up to 24 x 2.5” drives or 12 x 3.5” drives.
  • Take advantage of flexible I/O and networking options with PCIe Gen3-enabled expansion slots and your choice of vendor or embedded NIC technologies.
  • 2U rack
  •  Intel® Xeon® processor E5-2600 product family
  • 2 Processor sockets
  • 2 x Intel QuickPath Interconnect (QPI) links; 6.4 GT/s; 7.2 GT/s; 8.0 GT/s
  • 2.5MB Cache per core; core options: 2, 4, 6, 8
  • Intel C600 Chipset
  • Up to 768GB of memory (24 DIMM Slots): 2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s
  • 6 PCIe slots: • Two x16 full-length, full-height • One x8 full-length, full-height • Three x8 half-length, half-height
  • Internal controllers: PERC H310 PERC H710 PERC H710P
  • External HBAs (RAID): PERC H810
  • Up to twenty-six 2.5” drives or up to twelve 3.5” drives plus two 2.5” drives
  • Up to 50TB internal storage.
  • Hot-plug hard drive options: 2.5” SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K) 3.5” SAS (15K), nearline SAS (7.2K), SATA (7.2K)
  • Auto-ranging Titanium efficiency, hot-plug redundant 750W AC power supply; Auto-ranging Platinum efficiency, hot-plug redundant 495W, 750W or 1100W AC power supply; 1100W DC power supply
  • Supports ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm • ReadyRails static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded and 2-post (Telco) racks. (Rail kit not included)
  • Bezel not included

Dell PowerEdge R720xd Specs:

  • Brand: Dell
  • Product Line: PowerEdge
  • Product Type: Rackmount Server
  • Form Factor: 2U Rackmount
  • Processors: Up to 2x Intel Xeon Processor E5-2600 or E5-2600 v2
  • Memory: Up to 768GB PC3-10600R
  • Hard Drives: Up to 12x 3.5" SATA or SAS drives and 2x 2.5" bays in the rear.
  • Maximum Internal Storage: 50TB
  • I/O Slots: Six PCIe 3.0
  • Remote Management: iDRAC7 Express or iDRAC7 Enterprise
  • Power Supply Unit: Hotswap PowerSupply up to 1100Watts

What you will get:

  • Server: Dell R720XD BTO
  • CPU: Intel E5-2695v2 (1)
  • Memory: 32GB (2 x 16GB) RDIMM(PC3-10600R)
  • Hard Drive: None Included (Please contact us for Drives)
  • Caddy/Tray: None Included
  • Controller: H710 Integrated MiniMono RAID Controller
  • LAN: DELL BROADCOM 57800S 2 X 10GBE + 2 X 1GBE Controller
  • Rail Kit: None Included
  • Bezel: None Included
  • Remote Management: iDRAC7 Express
  • Power Supply Unit: 1100Watt PSU  (1)

Alternate MPNs: R720XD

Weight: 50 lb

Warranty: 2 Month DiscTech

Brand New

Condition Levels Explained

The product is brand new.

2 Month DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
