Dell WLD15 7DCTG / 61GRY / 452-BBUX E/Port Plus Wireless Docking Station with USB 3.0

Dell Part #/MPN: WLD15

DiscTech Item #: DEL-WLD15-BN-OE


$79.00
$79.00

Interface Types: USB 2.0, USB 3.0 3.1 3.2, Ethernet RJ45, DisplayPort, SVGA, 3.5mm Headphone

Voltage: 110-240V Multi

Dell WLD15 7DCTG / 61GRY E/Port Plus Wireless Docking Station with USB 3.0 (WiGig Capable)

DP/N - 61GRY, WLD15, 452-BBUX

The Dell Wireless Docking Station (WLD15: WiGig capable)

The Dell Wireless Dock (WLD15) is the second generation WiGig docking station for Dell. It is designed based on the Tri-band Intel 17265 802.11ad wireless local area network (WLAN) and Intel WiGig 1.1 specifications.

The WLD15 has the following features:

Video connections: 1 - mini-DisplayPort (DP1.2), 1 - HDMI (1.4) and 1 - Video Graphics Array (VGA)

I/O ports: 1 - Headset Connection, 1 - Speaker out

Network port: 1 - 10/100/1000 LAN Connection

USB: 2 - front USB 3.0 ports (one with Powershare), 1 - rear USB 3.0 port, 2 - rear USB 2.0 ports

Wireless status LED:

Search/Disconnected mode: Steady Amber

Connected mode: Steady White

Pairing: Amber blinking

Firmware upgrade: White blinking

Error: Alternating White and amber

Operating system support: Windows 7, 8, 8.1,& 10

System Requirements:

Computers equipped with an Intel WiGig antenna and Intel WiGig Module (Intel® Tri-Band Wireless-AC 17265 WiGig + WLAN + BT4.0LE Wireless Card) supporting WBE protocol

Compatible Systems.

Systems that are compatible with the WLD15 WiGig wireless dock meet the following minimum hardware/software requirements:

ePort e/Port e-Port

Equipped with an Intel WiGig antenna

Equipped with an Intel 17265 Tri-Band 802.11ad WLAN module

Microsoft Windows 7, 8, 8.1 or Windows 10 (Post release)

As of May 2015, WLD15 compatible systems include:


Latitude E7250

Latitude E7450

Latitude E5450

Latitude E5550

Latitude E5250


Compatibility:

Compatible Systems.

Systems that are compatible with the WLD15 WiGig wireless dock meet the following minimum hardware/software requirements:


Equipped with an Intel WiGig antenna

Equipped with an Intel 17265 Tri-Band 802.11ad WLAN module

Microsoft Windows 7, 8, 8.1 or Windows 10 (Post release)

As of May 2015, WLD15 compatible systems include:


Latitude E7250

Latitude E7450

Latitude E5450

Latitude E5550

Latitude E5250

ePort e/Port e-Port

The WLD15 has the following features:

Video connections: 1 - mini-DisplayPort (DP1.2), 1 - HDMI (1.4) and 1 - Video Graphics Array (VGA)

I/O ports: 1 - Headset Connection, 1 - Speaker out

Network port: 1 - 10/100/1000 LAN Connection

USB: 2 - front USB 3.0 ports (one with Powershare), 1 - rear USB 3.0 port, 2 - rear USB 2.0 ports

Wireless status LED:

Search/Disconnected mode: Steady Amber

Connected mode: Steady White

Pairing: Amber blinking

Firmware upgrade: White blinking

Error: Alternating White and amber

Operating system support: Windows 7, 8, 8.1,& 10


Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 7DCTG 61GRY 07DCTG 061GRY 452-BBUX

Weight: 8 lb

Warranty: 1 Year DiscTech

Brand New

1 Year DiscTech Warranty
