  • HPE 759202-001 / Seagate ST300MP0035 / 1MG200-035 300GB 2.5" 12Gbps 15K RPM 512e eMLC Enterprise SAS Hybrid Hard Drive

HPE 759202-001 / Seagate ST300MP0035 / 1MG200-035 300GB 2.5" 12Gbps 15K RPM 512e eMLC Enterprise SAS Hybrid Hard Drive

Seagate Part #/MPN: ST300MP0035

DiscTech Item #: SGT-ST300MP0035-RF-OE-HPI


$29.99
$29.99

Enterprise Grade

Capacity: 300GB

Speed: 15,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: 246 to 180

Average Seek Time: 2.0

Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps

On-Board Cache: 128MB

SSD Type: MLC

Hybrid SSD Cache: 32GB/MLC NAND

HPE 759202-001 / Seagate ST300MP0035 / 1MG200-035 300GB 2.5 12Gbps 15K RPM 512e eMLC Enterprise SAS Hybrid Hard Drive - Refurbished

HPE 759202-001 / Seagate ST300MP0035 / 1MG200-035 300GB 2.5" 12Gbps 15K RPM 512e eMLC Enterprise SAS Hybrid Hard Drive - Refurbished

Enterprise Performance 15K HDD

High-Performing, Up to 600GB, Small Form Factor 15K Hard Drive

  • Stores twice the amount of Tier 1 data over previous generation, without increasing drive count, in 2.5-inch form factor
  • Enables faster transaction processing, which can result in increased revenue generation and improved customer satisfaction
  • Latest 12Gb/s SAS interface for improved scalability
  • Industry’s highest MTBF at 2.0M hours
  • Support for all drive formats, including 512 Native, 512 Emulation and 4K Native
  • Provides up to 18% improvement in SDR performance over prior generation
  • SAS-based Protection Information (PI) helps protect against inadvertent data change.
  • Self-Encrypting Drive (SED) option (AES-256) helps cut IT drive retirement costs while helping securely protect data where it lives—on the drive.
  • SED models can be used as standard drives, as ISE feature for easy drive disposal or as part of a more secure solution.
  • FIPS Self-Encrypting Drive option helps protect Sensitive but Unclassified and Protected class data.

Best-Fit Applications

  • High-performance Tier 1 enterprise servers
  • Blade, rack and tower servers hosting transaction-based applications
  • Power- and space-constrained data centers
  • Compliance and data security initiatives


Compatibility:

This drive is compatible with any server that accepts 2.5"x15mm (SFF) SAS drives.

SPECIFICATIONS
Standard ModelST300MP0035
Specification512 Emulation
Capacity300GB
Interface12Gb/s SAS
PERFORMANCE
Average Latency (ms)2.0
Sustained Transfer Rate (Outer to Inner Diameter) MiB/s246 to 180
Max. Instantaneous Transfer Rate (SAS dual port) MB/s2400
Cache, Multisegmented (MB)128
TURBOBOOST ENHANCED CACHE
NAND Flash TypeeMLC
NAND Flash Size32GB
CONFIGURATION/RELIABILITY
Disks/Heads2/4
Nonrecoverable Read Errors per Bits Read, Max1 per 10e16
Annualized Failure Rate (AFR)0.44%
POWER MANAGEMENT
Typical Op (A) +5V/+12V0.46/0.51
Average Idle Power (W)4.8
Average Operating Power (W)8.4
ENVIROMENTAL
Ambient Temperature, Operating (C°)5 to 55
Ambient Temperature, Nonoperating (C°)-40 to 70
Temperature Change Rate/Hr, Max (C°)20
Relative Humidity, Noncondensing (max gradient 20% hour)5% to 95%
Shock, Max Operating: 11ms (Gs)40
Shock, Max Nonoperating: 2ms (Gs)400
Vibration, Operating: <400Hz (Gs)0.5
Vibration, Nonoperating: <500Hz (Gs)2.4
PHYSICAL
Height (in/mm, max)0.591/15.00
Width (in/mm, max)2.750/69.85
Depth (in/mm, max)3.955/100.45
Weight (lb/kg)0.496/0.225

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 759202-001 1MG200-035

Weight: 1 lb

Warranty: 1 Year DiscTech

Refurbished

Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
