Seagate Part #/MPN: ST1000NX0313
DiscTech Item #: SGT-ST1000NX0313-BN-OE-HPI
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 1TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 2.5inx15mm SFF Server Drive
Sector Size: 512 / 512e
Sustained Throughput: 136
Average Seek Time: 4.16
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 128MB
HPE / Seagate ST1000NX0313 1TB 2.5” 6Gbps 7.2K RPM Enterprise 512e SATA HDD – Brand New
HPE / Seagate ST1000NX0313 1TB 2.5” 6Gbps 7.2K RPM Enterprise 512e SATA HDD
Design Small and Deliver BIG – 2.5-Inch Nearline Drive
- High capacity in 15mm z-height, 2.5-inch form factor for space-constrained data centers.
- Designed for high-density storage solutions requiring environmentally sound low power consumption and low weight for maximum storage efficiency.
- Choose SATA 6Gb/s for economical nearline performance.
- Third-generation, enterprise-class reliability for 24x7 environmental robustness.
- Highest efficiency with over 50% improvement in watts/TB, and 18% sequential performance improvement compared to the previous generation.
- Improved rotational vibration tolerance and head micro-actuation maximizes system availability and performance.
- Lowest enterprise operating power and enhanced PowerChoice™ options for additional power saving during idle periods.
Best-Fit Applicaions
- Storage-hungry business applicaions.
- Storage area networks (SAN) and network attached storage (NAS).
- Maximum-capacity entry-level server and blade servers.
- Rich media content storage.
- Enterprise backup and restore – D2D, virtual tape.
- Cloud computing.
Compatibility:
This drive is compatible with any server that accepts 2.5"x15mm (SFF Hard Drive) SATA drive.
Drive Model | ST1000NX0313 |
---|---|
Capacity | 1TB |
Interface | SATA 6Gb/s |
Performance | |
SED Model | No |
PowerChoice™ on-demand power option | Yes |
Low Halogen | Yes |
RAID Rebuild™ | Yes |
Reliability/Data Integrity | |
Mean Time Between Failures (MTBF, hours) | 1.4 million |
Reliability Rating @ Full 24x7 operation (AFR) | 0.63% |
Nonrecoverable Read Errors per Bits Read | 1 sector per 10E15 |
Power-On Hours per Year | 8760 |
Bytes per Sector | 512 |
Performance | |
Spindle Speed (RPM) | 7200 |
Cache Buffer, Multisegmented (MB) | 128 |
Interface Access Speed (Gb/s) | 6.0, 3.0, 1.5 |
Max. Sustained Transfer Rate (MB/s) | 136 |
Average Latency (ms) | 4.16 |
Interface Ports | Single |
RV Tolerance (rad/s to 1800Hz) | 16 |
Power Management | |
Idle Power (W) | 3.51 |
Typical Operating, Random Read (W) | 4.74 |
PowerChoice™ Technology (Standby) (W) | 1.14 |
Power Supply Requirements | +12V and +5V |
Environmental | |
Temperature, Operating (˚C) | 5 to 55 |
Vibration, Operating, 5Hz to 500Hz (Gs) | 0.5 |
Vibration, Nonoperating, 5Hz to 500Hz (Gs) | 3.0 |
Shock, Operating, 2ms (Gs) | 25 |
Shock, Nonoperating, 2ms (Gs) | 400 |
Acoustics, Typical Idle (bels) | 2.8 |
Acoustics, Typical Seek (bels) | 3.2 |
Physical | |
Height (mm/in) | 15.00/0.591 |
Width (mm/in) | 70.10/2.760 |
Depth (mm/in) | 100.45/3.955 |
Weight (g/lb) | 190/0.419 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 765451-001
Weight: 1.5 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
