Hitachi 450GB 3.5 0B24768 / HUS156045VLS601 SAS Hard Disk Drive

Hitachi Part #/MPN: 0B24768

DiscTech Item #: HIT-0B24768-RF-OE


$249.00
$249.00

Enterprise Grade

Capacity: 450GB

Speed: 15,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 119 to 198

Average Seek Time: 3.4

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps

On-Board Cache: 64MB

Compatible Systems: Dell 10th Gen. 2950 / 6950

Hitach Ultrastar 15K600 450GB 15K RPM 6.0Gbps Serial SCSI / SAS Hard Drive 0B24768 / HUS156045VLS601 - Refurbished

Ultrastar™ 15K600

The all-in-one enterprise drive delivers performance and capacity in one package

Combines ultimate performance with high capacity in the same drive. The 6Gb/s Serial Attached SCSI (SAS) and 4Gb/s Fibre Channel Arbitrated Loop (FCAL) interfaces support the reliability required in the most demanding enterprise computing environments.

Hitachi Part Numbers: 0B24768 / HUS156045VLS601


Compatibility:

All SAS compatible servers including:

IBM, HP Proliant, Dell PowerEdge 1900, 1950, 2900, 2950, 6900, 6950, T3xx, T6xx, R series, and  PowerVault MD1000.

Device TypeHard drive - internal
Approximate Width4 in
Approximate Depth5.7 in
Approximate Height1 in
Approximate Weight1.7 lbs

Hard Drive

Form Factor3.5" x 1/3H
Capacity450 GB
Interface TypeSerial ATA-600 / SAS
Buffer Size64 MB
FeaturesFluid Dynamic Bearing (FDB) motor, load/unload technology, Rotational Vibration Safeguard (RVS)

Performance

Drive Transfer Rate600 MBps (external)
Seek Time3.4 ms (average)
Average Latency2 ms
Spindle Speed15000 rpm

Reliability

MTBF1,600,000 hour(s)
Non-Recoverable Errors1 per 10^16

Expansion / Connectivity

Interfaces1 x Serial ATA-600
Compatible Bays1 x internal - 3.5" x 1/3H

Miscellaneous

Compatible with Windows 7"Compatible with Windows 7" software and devices carry Microsoft’s assurance that these products have passed tests for compatibility and reliability with 32-bit and 64-bit Windows 7.

Environmental Parameters

Min Operating Temperature41 °F
Max Operating Temperature131 °F
Shock Tolerance30 g @ 2ms half-sine pulse (operating) / 250 g @ 2ms half-sine pulse (non-operating)
Vibration Tolerance1.5 g @ 5-500 Hz (operating) / 2 g @ 5-500 Hz (non-operating)


Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: HUS156045VLS601

Weight: 1.8 lb

Warranty: 1 Year DiscTech

Refurbished

Condition Levels Explained

These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
