Hitachi Part #/MPN: 0F23009
DiscTech Item #: HIT-0F23009-BN-5Y
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:5 Year ManufacturerProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
- In Stock:6Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 2TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 227/202
Average Seek Time: 4.16
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 128MB
Hitachi Ultrastar 7K6000 0F23009 / HUS726020ALE610 2TB 6Gbps 7.2K RPM 512e Enterprise SATA HDD - Brand New
Hitachi Ultrastar 7K6000 0F23009 / HUS726020ALE610 2TB / 2000GB 6Gbps 7200 RPM 512 Emulation Enterprise Serial ATA Hard Disk Drive - Brand New
Alt Model Number: HUS726020ALE610
Hitachi Ultrastar 7K6000 Enterprise Hard Drive
- Best-in-class random & sequential performance
- Reliable, field-proven, 7th generation 5-disk design
- Technology Innovation Improves Storage Efficiency – include higher areal density for 25% faster sequential performance vs. 7K4000, and a 128MB cache buffer
Increasing Capacity Density by 50%
Ultrastar 7K6000 provides 50% more capacity and 30% better power efficiency in terms of Watts per terabyte (W/TB) than its predecessor, Ultrastar 7K4000. The 7K6000 is designed for all traditional and rapidly growing scale-out storage applications, including object, block and file storage architectures, providing huge capacity, the fastest 7,200 RPM performance and the best $/TB acquisition cost.
Compatibility:
This drive is compatible with any server that accepts 3.5in x 1.0in (LFF) SATA drives.
| Ultrastar® 7K6000 | |
|---|---|
| Model/Part No. | 0F23009 |
| Alt Model/Part No. | HUS726020ALE610 |
| Data Security Mode | Instant Secure Erase |
| Capacity | 2TB/2,000GB |
| Interface | SATA 6Gbps |
| Form Factor | 3.5-inch |
| Sector size (bytes) | 512n*/512e: 5126 |
| Performance | |
| Data buffer (MB) | 128 |
| Rotational speed (RPM) | 7200 |
| Latency average, (ms) | 4.16 |
| Interface transfer rate (MB/s, max) | 600 |
| Sustained transfer rate (MB/s typical) (MiB/sec, typ) (MB/sec, typ) | 216/192 227/202 |
| Seek time (read, ms, typical) | 7.6/8.0 |
| Reliability | |
| Error rate (non-recoverable, bits read) | 1 in 10E15 |
| Load/Unload cycles (at 40°C) | 600,000 |
| MFBF (M hours) | 2.0 |
| Annualized Failure Rate (AFR) | 0.44% |
| Availability (hrs/day x days/wk) | 24x7 |
| Acoustics | |
| Idle (Bels, typical) | 2.9/3.6 |
| Power | |
| Requirement | +5 V, +12V |
| Operating (W, typical) | 9.1 |
| Idle (W) | 7.1 |
| Power consumption efficiency at idle (Watts/TB) (Watts/GB) | 1.2 0.0012 |
| Physical size | |
| z-height (mm) | 26.1 |
| Dimensions (width x depth, mm) | 101.6 (+/-0.25) x 147 |
| Weight (g/lb max) | 715/1.57631 |
| Environmental (Operating) | |
| Power-On Hours | 5º to 60º C |
| Shock (half-sine wave 2 ms, G) | 70 |
| Vibration (G RMS 5 to 500 Hz) | 0.67 (XYZ) |
| Environmental (Non-Operating) | |
| Ambient temperature | -40º to 70º C |
| Shock (half-sine wave, 1ms, G) | 300 |
| Random vibration (G RMS 5 to 500 Hz) | 1.04 (XYZ) |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HUS726020ALE610
Weight: 1.8 lb
Warranty: 5 Year Manufacturer
Brand New
The product is brand new.
5 Year Manufacturer Warranty
The product has a manufacturer warranty for the time period specified.
