Toshiba Part #/MPN: MG04ACA200N
DiscTech Item #: TOS-MG04ACA200N-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:57Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 2TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 195
Average Seek Time: 4.17
Electrical Interface: SATA 600 - 6.0Gbps
Toshiba MG04ACA200N 2TB 3.5in 6Gbps 7.2K RPM Enterprise SATA Hard Drive - Brand New
The Enterprise Capacity HDD 512 native, 7,200 rpm SATA models (MG04ACA-N) come in a robust design providing 1, 2 and 4TB in a 3.5-inch form factor. Features of MG04ACA-N series include a SATA 6Gbit/s interface, and industry-standard 512 native format sector technology for environments and applications that require 512 native. Model options supporting Sanitize Instant Erase (SIE) are also available. This feature randomizes data instantly in case of unintended disclosure in the event that drives are re-purposed or moved outside of data center environments.
Key Features
- Large-Capacity (4 / 2 / 1 TB models) in an industry standard 3.5-inch Form-Factor
- 7,200 rpm Performance
- SATA 6Gbit/s Interface
- Designed for 24 × 7 workloads of up to 550 total TB Transferred per Year
- 512 Native Sector Technology
- Rotational Vibration Technology
- Sanitize Instant Erase (SIE) Option Available
Applications
- Engineered for Mid-line / Nearline Business Critical Workloads
- Tier 2 Business-Critical Servers and Storage Systems
- Servers Supporting Workloads that Benefit from High Capacity per Spindle
- Capacity-Optimized Data Center Storage Systems
- Applications and hypervisors that require legacy 512 Native Sector Technology
MP/N: HDEPR03GHA51F
Compatibility: This drive is compatible with any server or workstation that accepts 3.5in x 1.0in (LFF) SATA drives.
| Enterprise SATA HDD | |
|---|---|
| Model Number | MG04ACA200N |
| Basic Specifications | |
| Interface | SATA-2.6 / 3.0 |
| Interface Speed | 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit/s |
| Formatted Capacity | 2TB / 2000GB |
| Logical Data Block Length (HOST) | 512 |
| Logical Data Block Length (DISK) | 512 |
| Environmental Compliance | RoHS Compatible |
| Performances | |
| Buffer Sizee | 128 MiB |
| Rotation Speed | 7,200 rpm |
| Average Latency Time | 4.17 ms |
| Data Transfer Speed (Sustained) | 195 MiB/s |
| Reliability | |
| Unrecoverable Error Rate | 10 per 10e16 bits read |
| MTTF | 1,400,000 hors |
| 24 x 7 Operation | Yes |
| Workloads | 550 TB/y |
| Power Requirements | |
| Supply Voltage | 5 V ±5 % , 12 V ±5 % |
| Power Consumption (Read / Write) | 11.3 W |
| Power Consumption (Idle-B) | 6.0 W Typ |
| Dimensions | |
| Height | 26.1 mm Max |
| Width | 101.6 mm ± 0.25 mm |
| Lenth | 147 mm Max |
| Weight | 720 g Max |
| Environmental Requirements | |
| Temperature (Operating) | 5 to 55 °C |
| Temperature (Non-operating) | -40 to 70°C |
| Humidity (Operating) | 5 to 90 % R.H. |
| Humidity (Non-operating) | 5 to 95 % R.H. |
| Altitude (Operating) | -305 to +3,048 m |
| Altitude (Non-operating) | -305 to +12,192 m |
| Vibration (Operating) | |
| Vibration (Non-operating) | 49 m/s2 { 5.0 G } ( 5 to 500 Hz ) |
| Shock (Operating) | 686 m/s2 { 70 G } ( 2 ms duration ) |
| Shock (Non-operating) | 2,940 m/s2 { 300 G } ( 2 ms duration ) |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HDEPR03GHA51F
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
