Hitachi Deskstar 7K3000 0F12450 SATA Hard Drive

- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
Capacity: | 3TB |
Speed: | 7.2K RPM |
Interface Types: | SATA |
Form Factor: | 3.5" LFF Hard Drive |
Electrical Interface: | SATA 600 - 6Gbps |
RAM: | 64MB |
Description
Hitachi Deskstar 7K3000 0F12450 / HDS723030ALA640 3000GB / 3TB 7.2K SATA Hard Drive - Brand New
Highest capacity and reliability with a proven design
The Deskstar™ 7K3000 is Hitachi’s first hard drive to deliver an enormous three terabytes of storage capacity and 7200 RPM performance in a standard 3.5-inch form factor. The 7K3000 is also the first Hitachi hard drive with a 6Gb/s SATA interface, which along with its 64MB cache buffer delivers a big boost to performance over the previous generation product. The Deskstar 7K3000 is designed to allow manufacturers to leverage the benefits of the latest components and operating systems to deliver high-performance, high-capacity, power-efficient systems. Manufacturers planning to use the highest capacity 3TB drive in systems should consult the Hitachi High Capacity Technology Brief. Deskstar 7K3000 is also available in 2TB and 1.5TB models that accommodate existing systems, as well as new designs. .
Hitachi p/n: 0F12450 / HDS723030ALA640
Compatibility:
Manufacturers planning to use the highest capacity 3TB drive in systems should consult the Hitachi High Capacity Technology Brief.
Specifications
Model(s) | HDS723030ALA640 HDS723020BLA642 HDS723015BLA642 | ||||
Interface | SATA 6Gb/s | ||||
Capacity (GB) | 3TB / 2TB / 1.5TB | ||||
Sector size (variable, Bytes/sector) | 512 | ||||
Max areal density (Gbits/sq. in.) | 411 | ||||
Performance | |||||
Data buffer (MB) | 64 | ||||
Rotational Speed (RPM) | 7200 | ||||
Media transfer rate (Mbits/sec, max) | 1656 | ||||
Interface transfer rate (MB/sec, max) | 600 | ||||
Reliability | |||||
Error Rate (non-recoverable, bits read) | 1 in 1014 | ||||
Load/Unload Cycles | 3TB: 600,000 <3TB: 300,000 | ||||
Availability (hrs/day x days/wk) | 24x7 | ||||
Acoustics | |||||
Idle (Bels) | 3TB: 2.9 <3TB: 2.7 | ||||
Power | |||||
Requirement | 3TB: +5 VDC (+/-5%) +12 VDC (+10%/-8%) <3TB: +5 VDC (+/-5%) +12 VDC (+/-10%) | ||||
Requirement: Start-up (W, peak, max) | 1.2 (+5V), 2.0 (+12V) | ||||
Performance Idle | 3TB: 6.8 <3TB: 5.2 | ||||
Physical size | |||||
Z-height (mm) | 26.1 | ||||
Dimensions (width x depth, mm) | 101.6 (+/-0.25) x 147 | ||||
Weight (g, max) | 3TB: 690 <3TB: 680 | ||||
Environmental (operating) | |||||
Ambient temperature | 3TB: 5º to 60º C <3TB: 0º to 60º C | ||||
Relative Humidity | 8% to 90% | ||||
Shock (half-sine wave) | 70 | ||||
Vibration | 0.67 (XYZ) (G RMS 5 to 500Hz) | ||||
Environmental (non-operating) | |||||
Ambient temperature | -40º to 70ºC | ||||
Relative Humidity | 5% to 95% | ||||
Shock (half-sine wave) | 3TB: 300 (1ms) <3TB: 300 (2ms) | ||||
Vibration | 1.04 (XYZ) (G RMS 2 to 200Hz) |
Capacity - One GB is equal to one billion bytes and one TB equals 1,000GB (one trillion bytes) when referring to hard drive capacity. Accessible capacity will vary from the stated capacity due to formatting and partitioning of the hard drive, the computer’s operating system, and other factors.
Data Buffer - Portion of buffer capacity used for drive firmware
Availability - Intended for low duty cycle, non mission-critical applications in PC, gaming and external storage environments, which may vary from application to application. Note that customer environments may vary from application to application.
Click here to view the manufacturer's item description/brochure
Alternate MPNs: HDS723030ALA640
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
