Intel SSDSA2CW080G310 80GB SATA SSD

INTEL Part #/MPN: SSDSA2CW080G310

DiscTech Item #: INT-SSDSA2CW080G310-RF-OE


$44.00
$44.00

Capacity: 80GB

Speed: Solid State Memory

Interface Types: SATA

Form Factor: 2.5inx7mm Fits All laptops

Sector Size: 512 / 512e

Sustained Throughput: 270

Electrical Interface: SATA 300 - 3.0Gbps

SSD Type: MLC

Intel SSDSA2CW080G310 / SSDSA2CW080G3 80GB 2.5in 3Gbps MLC 320 Series SATA SSD - Refurbished

Intel SSDSA2CW080G310 80GB 2.5" 3.0 Gbps Multi-Level Cell 320 Series Serial Advanced Technology Attachment Solid State Disk Drive - Refurbished

Intel Model Number: SSDSA2CW080G3
Alt. Ordering Part Number: SSDSA2CW080G301

Overview

The Intel SSD 320 Series delivers leading performance for Serial Advanced Technology Attachment (SATA)-based computers by combining Intel's leading 25nm NAND Flash Memory technology with SATA 3Gb/s interface support, the Intel SSD 320 Series delivers sequential read speeds of up to 270 MB/s and sequential write speeds of up to 220 MB/s. The industry-standard form factors enable interchangeability with existing hard disk drives (HDDs) and native SATA HDD drop-in replacement with the enhanced performance, reliability, ruggedness, and power savings offered by an SSD.

As compared to standard SATA HDDs, the Intel SSD 320 Series offers these key features:



  • High I/O and throughput performance
  • Low power
  • Increased system responsiveness
  • High reliability
  • Enhanced ruggedness



Hot Plug Support

Hot Plug insertion and removal is supported in the presence of a proper connector and appropriate operating system (OS), as described in the SATA 2.6 specification. This product supports asynchronous signal recovery and issues an unsolicited COMINIT when first mated with a powered connector to guarantee reliable detection by a host system without hardware device detection.

SMART Logs

The Intel SSD 320 Series implements the following Log Addresses: 00h, 02h, 03h, 06h, and 07h. The Intel SSD 320 Series implements host vendor specific logs (addresses 80h-9Fh) as read and write scratchpads, where the default value is zero (0). Intel SSD 320 Series does not write any specific values to these logs unless directed by the host through the appropriate commands. The Intel SSD 320 Series also implements a device vendor specific log at address A9h as a read-only log area with a default value of zero (0).

Device Statistics

In addition to the SMART attribute structure, statistics pertaining to the operation and health of the Intel SSD 320 Series can be reported to the host on request through the Device Statistics log as defined in the ATA specification. The Device Statistics log is a read-only GPL/SMART log located at read log address 0x04 and is accessible using READ LOG EXT, READ LOG DMA EXT or SMART READ LOG commands.


Compatibility:

This drive is compatible with any server that accepts 2.5"x9mm (Fits in ALL laptops) SATA drives.

Intel Model NumberSSDSA2CW080G3
Ordering Part NumbersSSDSA2CW080G310
SSDSA2CW080G301
Capacity80GB
Form Factor2.5" 9.5mm
InterfaceSATA 3.0 (3Gb/s)
Lithography25 nm
ComponentsIntel NAND Flash Memory Multi-Level Cell (MLC) Technology
Essentials
Sequential Read270 MB/s
Sequential Write90 MB/s
Random Read (8GB Span)38000 IOPS
Random Read (100% Span)38000 IOPS
Random Write (8GB Span)10000 IOPS
Random Write (100% Span)300 IOPS
Latency - Read75 µs
Latency - Write90 µs
Power - Active150 mw (MobileMark 2007 Workload), 2.0 W (64K Sequential Write)
Power - Idle100 mw (DIPM), .7 W (Non-DIPM)
Vibration - Operating2.17 GRMS (5-700 Hz)
Vibration - Non-Operating3.13 GRMS (5-800 Hz)
Shock (operating and Non-Operating)1,500 G/.5 msec
Operating Temperature Range0°C to 70°C
Mean Time Between Failures (MTBF)1,200,000 Hours
Uncorrectoable Bit Error Rate (UBER)1 sector per 100,000,000,000,000,000
Enhanced Power Loss Data ProtectionYes
Weight (g/lb)90/0.198

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: SSDSA2CW080G301 SSDSA2CW080G3
