INTEL Part #/MPN: SSDSC2BA400G3T
DiscTech Item #: INT-SSDSC2BA400G3T-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Capacity: 400GB
Speed: Solid State Memory
Interface Types: SATA
Form Factor: 2.5inx7mm Fits All laptops
Encryption/SED Supported
Sector Size: 512 / 512e
Sustained Throughput: 500
Electrical Interface: SATA 600 - 6.0Gbps
SSD Type: MLC
SSD Endurance DWPD: Enterprise Mixed Use
Intel SSDSC2BA400G3T / SSDSC2BA400G3 400GB 2.5in 6Gbps MLC SED DC S3700 Series SATA SSD - Brand New
Intel SSDSC2BA400G3T 400GB 2.5" 6.0 Gbps Multi-Level Cel Self-Encrypting Drive DC S3700 Series Serial Advanced Technology Attachment Solid State Disk Drive - Brand New
Intel Model Number: SSDSC2BA400G3
Ordering Part Number: SSDSC2BA400G301
Intel® Solid-State Drive DC S3700 Series
Consistently amazing
Ensuring fast and consistent command response times with low power consumption, the Intel® Solid-State Drive DC S3700 delivers superior performance with 4 KB random read performance of up to 75,000 input/output operations per second (IOPS)1 and 4 KB write performance of up to 36,000 IOPS1 while reducing overall energy costs. In addition to efficient performance, the Intel® SSD DC S3700 protects data loss and corruption with full end-to-end security. Combining an advanced error correction scheme in the NAND, SRAM, and DRAM memory, this Intel SSD also protects data in transit through parity checks, cyclic redundancy checks (CRC), and logical block address (LBA) tag validation. Furthering data assurance is the Advanced Encryption Standard (AES) and enhanced power-loss protection. And with High Endurance Technology (HET), the Intel SSD DC S3700 meets the most demanding write needs, achieving ten writes per day over a five-year life.
Compatibility:
This drive is compatible with servers and laptops that accept 2.5"x7mm SATA drives.
PACKAGE SPECIFICATIONS | |
---|---|
Intel Model Number | SSDSC2BA400G3 |
Ordering Part Numbers | SSDSC2BA400G3T SSDSC2BA400G301 |
Components | Intel NAND Flash Memory Mult-Level Cell(MLC) Technology |
Capacity | 400GB |
Form Factor | 2.5" 7mm |
Interface | SATA3.0 6Gb/s |
Lithography | 25 nm |
ESSENTIALS | |
Sequential Read | 500 MB/s |
Sequential Wrtie | 460 MB/s |
Random Read (100% Span) | 75000 IOPS |
Random Wrtie (100% Span) | 36000 IOPS |
Latency - Read | 50 µs |
Latency - Write | 65 µs |
Power - Active | 5.4 mW |
Power - Idle | 650 mW |
Vibration - Operating | 2.17 GRMS (5-700 Hz) |
Vibration - Non-Operating | 3.13 GRMS (5-800 Hz) |
Shock (Operating and Non-Operating) | 1,000 G/0.5 msec |
Operating Temperature Range | 0°C to 70°C |
Weight g/lb | 75.6/0.1667 |
Endurance Rating (Lifetime Writes) | 10 drive wrties per day for 5 years |
Mean Time Between Failures (MTBF) | 2,000,000 Hours |
Uncorrectable Bit Error Rate (UBER) | 1 sector per 10^17 bits read |
ADVANCED TECHNOLOGIES | |
Enhanced Power Loss Data Protection | Yes |
Hardware Encryption | AES 256 bit |
High Endurance Technology (HET) | Yes |
Temperature Monitoring and Logging | Yes |
End-to-End Data Protection | Yes |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: SSDSC2BA400G301 SSDSC2BA400G3
