Maxtor Part #/MPN: 8J073J0
DiscTech Item #: MAX-8J073J0-FR-6M
- Factory RefurbishedCondition Levels Explained
The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items.
Product Warranties ExplainedThe product has a manufacturer warranty for the time period specified.
- Warranty:6 Month Manufacturer
- In Stock:4Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 73GB
Speed: 10,000RPM
Interface Types: SCSI 80pin SCA-2 Hot-Swap
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 89
Average Seek Time: 4.0 / 4.5
Electrical Interface: SCSI LVD U320 - 320MBps 16-bit
On-Board Cache: 8MB
* RoHS Compliant
* Industry's highest 10K performance
* Formatted capacity: 73.4GB, 147.1GB, 300GB
* Seek time as fast as 4.0ms
* Designed for 1.4 million hours MTTF
* Third-generation Ultra320 SCSI
* MaxAdapt® intelligent drive technology
* 89MB/s maximum sustained data rate
* 8MB cache buffer
* Enhanced S.M.A.R.T. features
* Thermal sensor
| Specifications | 73.5 GB | 147.1 GB | 300 GB |
| Formatted Capacity (GB) | 73.5 | 147.1 | 300 |
| Bytes per Sector | 512 | 516 | 518 |
| Interface Ultra 320 SCSI (Backwards compatible with Ultra160, Ultra2, Ultra SCSI) | |||
| Interface Connectors 68-pin WIDE and 80-pin SCA-2 | |||
| Average Read/Write (ms) | 4.0/4.5 | 4.2/4.7 | 4.4/4.9 |
| Track-to-Track Read/Write (ms) | 0.3/0.5 | 0.3/0.5 | 0.3/0.5 |
| Full stroke Read/Write (ms) | 11.0/12.0 | 11.0/12.0 | 11.0/12.0 |
| Maximum Sustained Transfer Rate (MB/sec) | 89 | 89 | 89 |
| Operating Temperature (°C) | 5 to 55 | 5 to 55 | 5 to 55 |
| Non-Condensing Humidity (%) | 5 to 95 | 5 to 95 | 5 to 95 |
| Non-Operating Temperature (°C) | -40 to 70 | -40 to 70 | -40 to 70 |
| Idle Power (W) | 8.0 | 8.5 | 10.8 |
| Width max (inches/mm) | 4/101.6 | 4/101.6 | 4/101.6 |
| Length max (inches/mm) | 5.787/147 | 5.787/147 | 5.787/147 |
| Height max (inches/mm) | 1.028/26.1 | 1.028/26.1 | 1.028/26.1 |
| Weight max (lb/kg) | 1.8/0.82 | 1.8/0.82 | 1.8/0.82 |
Click here to view the manufacturer's item description/brochure
Weight: 1.8 lb
Warranty: 6 Month Manufacturer
Factory Refurbished
The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items.
The product has a manufacturer warranty for the time period specified.
6 Month Manufacturer Warranty
