Micron M500 MTFDDAK960MAV-1AE12ABYY / MK31D 1TB (960GB) SATA SSD
- Special Order - Call for Lead TimeSpecial Order - Call for Lead Time
This item has a variable lead time for fulfilment. Please call us to discuss. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 960GB |
| Speed: | Solid State |
| Interface Types: | SATA |
| Form Factor: | 2.5" x 7mm Fits All laptops |
| SSD Endurance DWPD: | Consumer / Value |
| Electrical Interface: | SATA 600 - 6Gbps |
Description
Micron M500 MTFDDAK960MAV-1AE12ABYY / MK31D 1TB (960GB) 6Gbps 2.5in Mixed-Use MLC SED SATA SSD - New Pull
Micron M500 MTFDDAK960MAV-1AE12ABYY 1TB (960GB) 6.0Gbps 2.5in x 7mm Multi Level Cell SED SATA SSD - New Pull
Alt DPNs: MK31D, 0MK31D
Micron’s solid state drive (SSD) uses a single-chip controller with a SATA interface on the system side and 8-channels of Micron NAND Flash internally. Packaged in an HDD replacement enclosure, the SSD integrates easily in existing storage infrastructures.
The SSD is designed to use the SATA interface efficiently during both READs and WRITEs while delivering bandwidth-focused performance. SSD technology enables enhanced boot times, faster application load times, reduced power consumption, and extended reliability.
The self-encypting drive (SED) features a FIPS-compliant, AES-256 encryption engine, providing hardware-based, secure data encryption, with no loss of SSD performance. This SED follows the TCG/Opal specification for trusted peripherals.
Compatibility
This drive is compatible with Servers, PC's and Laptops that accept 2.5"x7mm SATA drives.
Specifications
| Micron M500 SSD | |
|---|---|
| Model | MTFDDAK960MAV |
| Interface | 6Gb/s SATA |
| Capacity | 1TB / 960GB |
| Features | |
| Flash | MLC NAND Flash |
| Encryption | TCG/Opal 2.0-Complient Self-Encrypting drive |
| Sector Size | 512 |
| Sequential 128KB Read | Up to 500MB/s |
| Sequential 128KB Write | Up to 400MB/s |
| Random 4KB Read | Up to 80,000 IOPS |
| Random 4KB Write | Up to 80,000 IOPS |
| Read/Write Latency | 5ms / 25ms (MAX) |
| Power Consumption | 150MW (Typical) |
| Form Factor | 2.5" x7mm |
| Reliability/Data Integrity | |
| Mean Time Between Failures (MTBF, hours) | 1,200,000 |
| Total bytes written (TBW) | up to 500TB |
| Nonrecoverable Read Errors per Bits Read | 1 Sector per 1015 |
| Operating Temperature | 0°C - 70°C |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: MK31D 0MK31D
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Condition
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
Warranty
1 Year DiscTech Warranty
