Micron Part #/MPN: MTFDDAK960MAV-1AE12ABYY
DiscTech Item #: MIC-MTFDDAK960MAV-1AE12ABYY-BN-OE-DEG
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:318Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Capacity: 960GB
Speed: Solid State Memory
Interface Types: SATA
Form Factor: 2.5inx7mm Fits All laptops
Encryption/SED Supported
Sector Size: 512 / 512e
Average Seek Time: 5ms / 25ms (MAX)
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 128GB
SSD Type: MLC
SSD Endurance DWPD: Consumer / Value
Micron M500 MTFDDAK960MAV-1AE12ABYY / MK31D 1TB (960GB) 6Gbps 2.5in MLC SED SATA SSD - Brand New OEM
Micron M500 MTFDDAK960MAV-1AE12ABYY / Dell MK31D 1TB (960GB) 6.0Gbps 2.5in x 7mm MLC / Multi Level Cell SED SATA SSD / Solid State Drive - Brand New OEM
Alt DPNs: MK31D, 0MK31D
Micron’s solid state drive (SSD) uses a single-chip controller with a SATA interface on the system side and 8-channels of Micron NAND Flash internally. Packaged in an HDD replacement enclosure, the SSD integrates easily in existing storage infrastructures.
The SSD is designed to use the SATA interface efficiently during both READs and WRITEs while delivering bandwidth-focused performance. SSD technology enables enhanced boot times, faster application load times, reduced power consumption, and extended reliability.
The self-encypting drive (SED) features a FIPS-compliant, AES-256 encryption engine, providing hardware-based, secure data encryption, with no loss of SSD performance. This SED follows the TCG/Opal specification for trusted peripherals.
Compatibility:
This drive is compatible with Servers, PC's and Laptops that accept 2.5"x7mm SATA drives.
| Micron M500 SSD | |
|---|---|
| Model | MTFDDAK960MAV |
| Interface | 6Gb/s SATA |
| Capacity | 1TB / 960GB |
| Features | |
| Flash | MLC NAND Flash |
| Encryption | TCG/Opal 2.0-Complient Self-Encrypting drive |
| Sector Size | 512 |
| Sequential 128KB Read | Up to 500MB/s |
| Sequential 128KB Write | Up to 400MB/s |
| Random 4KB Read | Up to 80,000 IOPS |
| Random 4KB Write | Up to 80,000 IOPS |
| Read/Write Latency | 5ms / 25ms (MAX) |
| Power Consumption | 150MW (Typical) |
| Form Factor | 2.5" x7mm |
| Reliability/Data Integrity | |
| Mean Time Between Failures (MTBF, hours) | 1,200,000 |
| Total bytes written (TBW) | up to 500TB |
| Nonrecoverable Read Errors per Bits Read | 1 Sector per 1015 |
| Operating Temperature | 0°C - 70°C |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: MK31D 0MK31D MTFDDAK960MAV-1AE
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
