Seagate Part #/MPN: ST336607FC
DiscTech Item #: SGT-ST336607FC-RF-OE
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Enterprise Grade
Capacity: 36GB
Speed: 10,000RPM
Interface Types: Fibre Channel - Internal - Arbitrated Loop ASA II
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Average Seek Time: 4.7/5.3
Electrical Interface: FC-AL - 2Gbps
On-Board Cache: 4MB
Seagate Cheetah 10K.6 ST336607FC 36GB 10K 2Gbps 40pin Fibre / Fiber Channel Hard Drive - Refurbished
Key Features and Benefits
- Broad range of capacities—from 36 GB to 147 GB
- Lower ownership cost
- Super-fast data transfer rates
- Great value
Applications
- High-end enterprise workstations
- Data warehousing and data mining
- Multiuser multimedia
- Storage area networks (SAN)
- Digital audiovisual (A/V) and image processing
- Graphics and medial imaging
- Internet and e-commerce servers
Compatibility:
This drive is compatible with any of our Fibre channel drive trays.
| Technical Specifications | ||
| Description | ||
| Model number | ST336607FC | |
| Model Name | Cheetah 10K.6 | |
| Form Factor(width) | 3.5" | |
| Form Factor(height) | low-profile | |
| Physical Specifications | ||
| Height | 25.4 mm | |
| Width | 101.6 mm | |
| Length | 146.05 mm | |
| Weight | 0.73 kg | |
| Capacity/Interface | ||
| Formatted Capacity | 36.7 Gbytes, formatted | |
| Interface Type | 40-pin Fibre | |
| Performance | ||
| Transfer Rates | ||
| External (I/O) Transfer Rate (max) | 2 Gb/s | |
| Seek Times | ||
| Average Seek Time, Read | 4.7 msec typical | |
| Average Seek Time, Write | 5.3 msec typical | |
| Average Latency | 2.99 msec | |
| Other | ||
| Default Buffer (cache) Size | 8 MB | |
| Spindle Speed | 10,000 RPM | |
| Acoustics | ||
| Acoustics, Idle (sound power, typ) | 3.7 Bels | |
Click here to view the manufacturer's item description/brochure
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
