Seagate Constellation.2 ST9500620SS 500GB 7.2K 6.0Gbps SFF Serial SCSI / SAS Hard Disk Drives
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 3 Year ManufacturerWarrantyProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
| Capacity: | 500GB |
| Speed: | 7.2K RPM |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| Electrical Interface: | SAS-2 6Gbps |
| RAM: | 64MB |
Description
Seagate Constellation.2 ST9500620SS 500GB 7.2K 6.0Gbps SFF Serial SCSI / SAS Hard Drive - Brand New
The Constellation 7200 hard drive enables manageable nearline storage solutions in 2.5" chassis — either direct attach or in a tiered storage environment — at the lowest power usage without compromising performance or reliability. Constellation 500GB SATA drives deliver cost-effective, eco-friendly nearline storage.
Key Features and Benefits- Lowest operating power & enhanced power options with PowerChoice™ for even greater power savings during slow or idle periods
- First 2.5", 15mm business critical drive on the market designed for enterprise reliability, vibration performance and high data integrity. Fits in more server & storage slots!
- Fastest Tier 2/Nearline HDD on the market (SAS @ 6Gb/s speed). At a system level (with more drives) the performance will be >2x as compared to 3.5" HDD.
- The highest capacity 2.5" enterprise drive with 500GB with both SAS and SATA interfaces. (160GB SATA also available for boot/entry server applications)
- 6Gbps SAS 2.0 allows for easier integration, enhanced features and outstanding performance
- Government-grade self-encrypting drive (SED) on SAS models
- Best performing nearline drive with Best-in-class Rotational Vibration
Manufacturer's p/n: 9FY246, 9RZ264
Compatibility
This drive is compatible with any of our SAS drive trays and any of our SAS controllers.
Specifications
Drive specification | ST9500620SS |
Formatted Gbytes (512 bytes/sector) | 500 |
Bytes per sector | 512 |
Spindle speed (RPM) | 7,200 |
I/O data transfer rate (MBps) | 600 |
Cache buffer | 16 |
Interface Type | 6.0Gbps SAS |
Average latency | 4.16 ms |
Seek time (read / write) ms | 7.5 / 8.5 |
Cache | 64 MB |
Dimensions (HxLxW) mm | 15 / 100.45 / 70 |
Weight | 0.2 kg |
Operating Shock (Read) | 70G, 2ms |
Non-operating Shock | 400G, 2ms |
Temperature - Operating | 5C -55C |
Temperature - Non-operating | -40C - 70C |
Current Requirements 12VDC (Read/Write, Idle) | 3.5w / 2.6w |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 9FY246 9RZ264
Weight: 0.5 lb
Warranty: 3 Year Manufacturer
Condition
Brand New
Warranty
3 Year Manufacturer Warranty
