Seagate Part #/MPN: ST1000NX0423
DiscTech Item #: SGT-ST1000NX0423-RF-OE
$49.00
- Refurbished
- Warranty:1 Year DiscTech
- In Stock:11Need more?
Enterprise Grade
Capacity: 1TB
Speed: 7.2K RPM
Interface Types: SATA
Form Factor: 2.5" SFF Server Drive
Sector Size: 512 / 512e
Sustained Throughput: 136
Average Seek Time: 4.16
Electrical Interface: SATA 600 - 6Gbps
On-Board Cache: 128MB
Seagate ST1000NX0423 1TB 6Gbps 7.2K 2.5" SFF Enterprise SATA Hard Drive - Refurbished
Seagate Enterprise Capacity 2.5 HDD
Design Small and Deliver BIG—2.5-Inch Nearline Drive
- Up to 2TB capacity in 15mm z-height, 2.5-inch form factor for space-constrained data centers
- Designed for high-density storage solutions requiring environmentally sound low power consumption and low weight for maximum storage efficiency
- Choose 6Gb/s SATA for high data integrity, scalability and fast data access or SATA 6Gb/s for economical nearline performance.
- Third-generation, enterprise-class reliability for 24×7 environmental robustness
- Advanced sector formats (4K Native and 512 Emulation) as well as 512 Native support for legacy systems
- Highest efficiency with over 50% improvement in watts/TB, and 18% sequential performance improvement compared to the previous generation
- Improved rotational vibration tolerance and head micro-actuation maximizes system availability and performance.
- Lowest enterprise operating power and enhanced PowerChoice™ options for additional power savings during idle periods
- Protect data where it lives—on the drive—by choosing from government-grade SED FIPS 140-2 option or SED models with Seagate Instant Secure Erase technology for easy and cost-effective drive disposal.
Best-Fit Applications
- Storage-hungry business applications
- Storage area networks (SAN) and network attached storage (NAS)
- Maximum-capacity entry-level servers and blade servers
- Rich media content storage
- Enterprise backup and restore—D2D, virtual tape
- Cloud computing
Part # 1VE100-003
Compatibility:
This drive is compatible with any server that accepts 2.5"x15MM (SFF) SATA drives.
Specifications | |
---|---|
Standard Model Number | ST1000NX0423 |
Interface | SATA 6Gbps |
Format | 512 Native |
Features | |
PowerChoice™ On-Demand Power Option | Yes |
Protection Information | Yes |
Low Halogen | Yes |
RAID Rebuild™ | Yes |
Reliability/Data Integrity | |
Mean Time Between Failures (MTBF, hours) | 2.0 million |
Reliability Rating @ Full 24x7 operation (AFR) | 0.44% |
Nonrecoverable Read Errors per Bits Read | 1 sector per 10E15 |
Power-On Hours per Year | 8760 |
Bytes per Sector | 512 |
Performance | |
Spindle Speed (RPM) | 7200 |
Cache Buffer, Multisegmented (MB) | 128 |
Interface Access Speed (Gb/s) | 12.0, 6.0, 3.0 |
Max. Sustained Transfer Rate (MB/s) | 136 |
Average Latency (ms) | 4.16 |
Interface Ports | Dual |
RV Tolerance (rad/s to 1800Hz) | 16 |
Physical | |
Height (in/mm) | 0.591/15.00 |
Width (in/mm) | 2.760/70.10 |
Depth (in/mm) | 3.955/100.45 |
Weight (lb/kg) | 0.437/0.198 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 1VE100-003
Weight: 1 lb
Warranty: 1 Year DiscTech
Refurbished
1 Year DiscTech Warranty
