Seagate Part #/MPN: ST1000NX0423
DiscTech Item #: SGT-ST1000NX0423-RF-OE-DEL
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Enterprise Grade
Capacity: 1TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 2.5inx15mm SFF Server Drive
Sector Size: 512 / 512e
Sustained Throughput: 136
Average Seek Time: 4.16
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 128MB
Dell 31N08 / Seagate ST1000NX0423 1TB 6Gbps 7.2K 2.5" SFF Enterprise SATA Hard Drive - Refurbished Refurbished OEM
Alt DPNs: 31N08, 031N08
Enterprise Capacity 2.5 HDD
Design Small and Deliver BIG—2.5-Inch Nearline Drive
- Up to 2TB capacity in 15mm z-height, 2.5-inch form factor for space-constrained data centers
- Designed for high-density storage solutions requiring environmentally sound low power consumption and low weight for maximum storage efficiency
- Choose 6Gb/s SATA for high data integrity, scalability and fast data access or SATA 6Gb/s for economical nearline performance.
- Third-generation, enterprise-class reliability for 24×7 environmental robustness
- Advanced sector formats (4K Native and 512 Emulation) as well as 512 Native support for legacy systems
- Highest efficiency with over 50% improvement in watts/TB, and 18% sequential performance improvement compared to the previous generation
- Improved rotational vibration tolerance and head micro-actuation maximizes system availability and performance.
- Lowest enterprise operating power and enhanced PowerChoice™ options for additional power savings during idle periods
- Protect data where it lives—on the drive—by choosing from government-grade SED FIPS 140-2 option or SED models with Seagate Instant Secure Erase technology for easy and cost-effective drive disposal.
Best-Fit Applications
- Storage-hungry business applications
- Storage area networks (SAN) and network attached storage (NAS)
- Maximum-capacity entry-level servers and blade servers
- Rich media content storage
- Enterprise backup and restore—D2D, virtual tape
- Cloud computing
Compatibility:
This drive is compatible with any server that accepts 2.5"x15MM (SFF) SATA drives.
Specifications | |
---|---|
Standard Model Number | ST1000NX0423 |
Interface | SATA 6Gbps |
Format | 512 Native |
Features | |
PowerChoice™ On-Demand Power Option | Yes |
Protection Information | Yes |
Low Halogen | Yes |
RAID Rebuild™ | Yes |
Reliability/Data Integrity | |
Mean Time Between Failures (MTBF, hours) | 2.0 million |
Reliability Rating @ Full 24x7 operation (AFR) | 0.44% |
Nonrecoverable Read Errors per Bits Read | 1 sector per 10E15 |
Power-On Hours per Year | 8760 |
Bytes per Sector | 512 |
Performance | |
Spindle Speed (RPM) | 7200 |
Cache Buffer, Multisegmented (MB) | 128 |
Interface Access Speed (Gb/s) | 12.0, 6.0, 3.0 |
Max. Sustained Transfer Rate (MB/s) | 136 |
Average Latency (ms) | 4.16 |
Interface Ports | Dual |
RV Tolerance (rad/s to 1800Hz) | 16 |
Physical | |
Height (in/mm) | 0.591/15.00 |
Width (in/mm) | 2.760/70.10 |
Depth (in/mm) | 3.955/100.45 |
Weight (lb/kg) | 0.437/0.198 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 031N08 31N08
Weight: 1 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
