Seagate Part #/MPN: ST3300602FC
DiscTech Item #: SGT-ST3300602FC-NP-OE
- New PullCondition Levels Explained
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 300GB
Speed: 10,000RPM
Interface Types: Fibre Channel - Internal - Arbitrated Loop ASA II
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 150
Average Seek Time: 3.8 / 4.4
Electrical Interface: FC-AL - 4Gbps
On-Board Cache: 16MB
The Seagate Cheetah NS.2 drive reduces costs with the lowest-power, highest-capacity and highest-reliability solution for 3.5-inch Tier 1 requirements.
Key Advantages
- Lowest-power 3.5-inch Tier 1 drive (20 percent delta over runner-up).
- Highest-capacity Tier 1 drive (600 GBc.
- Highest reliability rating in the industry.
- Seagate PowerTrim technology dynamically reduces power usage.
- Supports 4-Gb/s Fibre Channel.
- Government-grade Self-Encrypting Drive option.
Compatibility:
| Specifications | |
| Model number | ST3300602FC |
| Model Name | Cheetah NS.2 |
| Form Factor(width) | 3.5-inch |
| Form Factor(height) | 1-inch |
| Height | 25.4 mm |
| Width | 101.6 mm |
| Length | 146.05 mm |
| Weight | 0.671 kg |
| Formatted Capacity | 300 Gbytes |
| Internal Transfer Rate (max) | 1840 Mbits/sec |
| External (I/O) Transfer Rate (max) | 400 MBytes/sec |
| Average Seek Time, Read | 3.8 msec typical |
| Average Seek Time, Write | 4.4 msec typical |
| Track-to-Track Seek, Read | 0.2 msec typical |
| Track-to-Track Seek, Write | 0.2 msec typical |
| Average Latency | 3 msec |
| Default Buffer (cache) Size | 16 Mbytes |
| Number of Discs (physical) | 2 |
| Number of Heads (physical) | 4 |
| Max Operating Shock (2-msec) | 60 Gs |
| Max Nonoperating Shock (2-msec) | 300 Gs |
| Operating Vibration (max) | 1.0 Gs |
| Nonoperating Vibration (max) | 3.0 Gs |
| Operating Temperature (max) | 55 deg C |
| Operating Temperature (min) | 5 deg C |
| Nonoperating Temperature (max) | 70 deg C |
| Nonoperating Temperature (min) | -40 deg C |
| Acoustics, Idle (sound power, typ) | 3.3 Bels |
| MTBF (Hours) | 1,600,000 hours |
| Nonrecoverable Read Errors | 1 per 10^16 bits read |
| Supports S.M.A.R.T. | Yes |
Click here to view the manufacturer's item description/brochure
Weight: 1.8 lb
Warranty: 1 Year DiscTech
New Pull
The product has been mounted in a brand new system (e.g. server), then removed from the system, before entering service. These products may have some hours of usage due to system build time / burn-in / testing etc. New Pulls are guaranteed to have at least 95% (often 99%) of their service life remaining , they may show signs of being physically mounted and dismounted. All handling is performed by trained technicians, taking full ESD precautions.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
