Seagate Part #/MPN: ST3320820AS
DiscTech Item #: SGT-ST3320820AS-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Capacity: 320GB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Average Seek Time: 4.16
Electrical Interface: SATA 300 - 3.0Gbps
On-Board Cache: 8MB
Seagate Barracuda 7200.10 320GB 7.2K 3Gbps SATA Hard Drive - ST3320820AS - Brand New
- Broad range of capacities, from 200 GB to 750 GB, the highest in the industry
- Available interfaces: SATA 3Gb/s, SATA 1.5Gb/s or Parallel ATA/100
- Perpendicular recording technology for maximum drive capacity and reliability
- 8- and 16-MB cache buffer options
- Ultra-fast performance
- Superb reliability
- Whisper-quiet operation
- Enhanced G-Force Protection against handling damage
- 78 MB/s maximum sustained data transfer rate
- Clean Sweep calibration and Directed Offline scan diagnostics
- RoHS (restriction of hazardous substances) compliant
Compatibility:
This drive is compatible with any computer that supports SATA hard drives.
| Specifications | |
|---|---|
| Model number | ST3320820AS |
| Model Name | Barracuda 7200.10 |
| Formatted Capacity | 320 Gbytes |
| Guaranteed Sectors | 625,142,448 |
| Rotational Speed | 7,200 rpm |
| Default Buffer (cache) Size | 8 Mbytes |
| Performance | |
| External (I/O) Transfer Rate (max) | 300 MBytes/sec |
| Average Seek Time (Read / Write) | 8.5 / 10 |
| Average Latency | 4.16 msec |
| Physical | |
| Form Factor(width) | 3.5-inch |
| Form Factor(height) | 1-inch |
| Height | 26.1 mm |
| Width | 101.6 mm |
| Length | 147 mm |
| Weight | 0.635 kg |
| Electrical | |
| Maximum start current | 2.80 |
| Environmental | |
| Operating Temperature (max) | 55 deg C |
| Operating Temperature (min) | 5 deg C |
| Nonoperating Temperature (max) | 70 deg C |
| Nonoperating Temperature (min) | -40 deg C |
| Acoustical | |
| Acoustics, Idle (sound power, typ) | 2.8 Bels |
| Reliability | |
| MTBF | 700,000 hours |
