Seagate ST400FM0053 400GB SAS SSD
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
- 5 Year ManufacturerWarrantyProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
| Capacity: | 400GB |
| Speed: | Solid State |
| Interface Types: | SAS |
| Form Factor: | 2.5" x 7mm Fits All laptops |
| SSD Endurance DWPD: | Enterprise Mixed Use / MU |
| Electrical Interface: | SAS-3 12Gbps |
Description
Seagate ST400FM0053 400GB 2.5" 12.0Gbps Enterprise Statistical Analysis System Ultra-fast Multi-Level Cell Solid State Disk Drive - Refurbished
Ultra-Fast, Consistent Performance Plus 12Gb/s SAS
- Helps remove storage bottlenecks and close the gap between processor and data access performance
- Delivers the speed and performance consistency needed for demanding enterprise applications
- Designed to reduce data access wait times under the most complex, write-intensive workloads
- First SSD to ship in volume with 12Gb/s SAS while ensuring the highest level of reliability and scalability
- Ensures data availability for critical production systems by using redundant, failover I/O communication paths
- Helps improve ROI by leveraging existing SAS infrastructures
- Custom-designed controller leverages Seagate enterprise expertise and manufacturing excellence
- Helps safeguard data against unexpected power loss and protects data from undetected, unintentional corruption
- Helps ensure data integrity with multiple layers of I/O error detection and correction
Best-Fit Applications
- Demanding, enterprise applications with complex, write-intensive and mixed workloads
- IOPS-hungry enterprise applications, such as high-performance computing, online transaction processing and heavy data analytics
- Enterprise applications that demand high data availability and integrity as well as interface failover redundancy
- External enterprise storage solutions (SAN, NAS, DAS) and servers
Alt. PNs: 1GD262-006
Compatibility
This drive is compatible with any server that accepts 2.5" x 7mm (Thin/Case) SAS drives.
Specifications
| Drive Model | ST400FM0053 |
|---|---|
| Capacity | 400GB |
| Performance | |
| Interface Option | 12Gbps SAS |
| NAND Flash Type | MLC |
| Sustained Data Transfer Rate, Max (MB/s) | 750 |
| I/O Data Transfer Rate, Max (MB/s) | 1200 |
| I/Os per Second per Watt (IOPS/W) | 29,650 |
| Sequential Read/Write Command Rate (MB/s) Peak, 128KB | 750/500 |
| Random Read/Write Command Rate (IOPS) Peak, 4KB | 110,000/40,000 |
| Configuration/Reliability | |
| Nonrecoverable Read Errors per Bits Read, Max | 1 per 10E16 |
| Annualized Failure Rate (AFR) | 0.44% |
| Total Terabytes Written (TBW) Over Warranty Period | 7300 |
| Power Management | |
| +5/+12V Max Start Current (A) | 0.7/0.4 |
| Average Sleep Power (W) | 2.5 |
| Average Idle Power (W) | 2.72 |
| Average Operating Power (W) | 3.71 |
| Enviromental | |
| Internal Operating Temperature (°C) | 0 to 60 |
| Nonoperating Temperature (°C) | −40 to 70 |
| Temperature Change Rate/Hr, Operating Max (°C) | 20 |
| Temperature Change Rate/Hr, Nonoperating Max (°C) | 20 |
| Relative Humidity, Noncondensing (%) | 5 to 95 |
| Shock, 0.5ms(Gs) | 1000 |
| Vibration, 20Hz to 2000Hz Grms) | 11.08 |
| Physical | |
| Height (mm/in) | 7.0/0.276 |
| Width (mm/in) | 70.10/2.76 |
| Length (mm/in) | 100.45/3.955 |
| Weight (g/lb) | 100/0.220 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 1GD262-006
Weight: 1.8 lb
Warranty: 5 Year Manufacturer
Condition
Refurbished
Warranty
5 Year Manufacturer Warranty
