Seagate Part #/MPN: ST5000NM0024
DiscTech Item #: SGT-ST5000NM0024-RF-OE
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Enterprise Grade
Capacity: 5TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 216
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 128MB
Seagate ST5000NM0024 / 1HT170-500 5TB 3.5in 6Gbps 7.2K RPM Enterprise SATA HDD - Refurbished
Seagate ST5000NM0024 5000GB 3.5" 6.0 Gbps 7200 RPM Enterprise Serial Advanced Technology Attachment - Refurbished
Seagate Model Number: 1HT170-500
Enterprise Capacity 3.5 HDD - Capacity-Optimized Enterprise Hard Drive for Bulk-Data Applications
- Highest-capacity large form factor enterprise drive—50% more capacity over last generation with up to 6TB—for demanding data growth.
- Fastest high-capacity HDD with best-in-class random and sequential read/write performance.
- Eighth-generation drive technology for reliable access to bulk storage of unstructured data.
- SATA 6Gb/s interfaces for easy integration into replicated and RAID storage systems.
- Industry-leading rotational vibration tolerance ensures consistent performance.
- Improved power and cooling efficiencies with low power consumption and on-demand PowerChoice™ technology based on T10/T13 power management standards.
- Engineered for 24×7 workloads of 550TB/yr—10× that of desktop drives.
- Robust performance with dual processors, ramp load technology, top-cover attached motor and humidity sensor for optimum performance in all chassis.
Best-Fit Applications
- Hyperscale applications
- High-capacity RAID storage
- Mainstream enterprise external storage arrays (SAN, NAS, DAS)
- Cloud data centers—replicated bulk data storage
- Enterprise backup and restore—D2D, virtual tape
- Centralized surveillance
Compatibility:
This drive is compatible with any server that accepts 3.5"x 1.0" (LFF) SATA drives.
| SPECIFICATIONS | |
|---|---|
| PART NUMBER | ST5000NM0024 |
| Seagate Part Number | 1HT170-500 |
| Capacity | 5TB/5000GB |
| Interface | SATA 6Gb/s |
| FEATURES | |
| Humidity Sensor | Yes |
| Super Parity | Yes |
| Low Halogen | Yes |
| PowerChoice Technology | Yes |
| Hot-Plug Support | Yes |
| Cache, Multisegmented (MB) | 128 |
| RELIABILITY/DATA INTEGRITY | |
| Mean Time Between Failures (MTBF, hours) | 1.4M |
| Reliability Rating @ Full 24x7 Operation (AFR) | 0.63% |
| Nonrecoverable Read Errors per Bits Read | 1 sector per 10e15 |
| Sector Size (Bytes per Sector) | 512 |
| Power-On Hours per Years | 8760 (24x7) |
| PERFORMANCE | |
| Spindle Speed (RPM) | 7200 |
| Interface Access Speed (Gb/s) | 6.0, 3.0, 1.5 |
| Max Sustained Transfer Rate OD (MB/s) | 216 |
| Average Latency (ms) | 4.16 |
| Interface Ports | Single |
| Rotational Vibration @ 1500 Hz (rad/s) | 12.5 |
| POWER CONSUMPTION | |
| Idle Power, Average (W) | 6.9 |
| Typical Operating, Random Read (W) | 11.27 |
| Power Supply Requirements | +12V and +5V |
| ENVIRONMENTAL | |
| Temperature, Operating (°C) | 5 to 60 |
| Vibration, Nonoperating: 10Hz to 500Hz (Grms) | 5.0 |
| Shock, Operating, 2ms (Read/Write) (Gs) | 70/40 |
| Shock, Nonoperating, 1ms and 2ms (Gs) | 300 |
| PHYSICAL | |
| Height (in/mm, max) | 1.028/26.1 |
| Width (in/mm, max) | 4.010/101.85 |
| Depth (in/mm, max) | 5.878/147.0 |
| Weight (lb/g) | 1.720/780 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 1HT170-500
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
