Seagate ST600MP0036 600GB 2.5" SFF 12Gbps 15K SAS HDD Hard Drive
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 600GB |
| Speed: | 15K RPM |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| Electrical Interface: | SAS-3 12Gbps |
| RAM: | 256MB |
Description
Seagate ST600MP0036 600GB 2.5" SFF 12Gbps 15K.6 RPM 512n SAS HDD Hard Drive - Refurbished OEM
Seagate ST600MP0036 600GB 2.5" SFF 12Gbps 15K.6 RPM 512n SAS HDD Hard Drive - Refurbished OEM
This drive has been reformatted to 512 bytes, Compatible with all normal SAS controllers and server systems (e.g. Dell, HPE, Supermicro). It has 1,171,875,000 512k data blocks which is slightly smaller capacity than other 600GB drives. For New RAID volumes only.
Enterprise Performance 15K HDD
Performance You Need, Versatility You Want, Affordability You Demand
- Accelerates I/O operations and completes more transactions faster — even during peak demand
- At 900 GB, stores 50% more mission-critical data than any other 15K HDD
- Optimizes TCO with higher capacity at lower cost than high-performance alternatives
- Delivers more predictable performance (up to 27% SDR over previous generation ) while helping to protect data from corruption due to unexpected power loss
- Supports all drive formats including 512 native and a single Fast Format™ model for advanced formats (4Kn and 512e) that simplifies HDD management
- Industry-leading read caching with TurboBoost™ technology for optimum response times — perfect for OLTP applications
- Advanced Write Caching feature utilizing enhanced algorithms for the industry’s highest mission-critical storage workload performance efficiencies
- Uses traditional NAND and advanced algorithms to promote hot data and achieve performance improvement (up to 2.6× improvements over last generation )
- Enables high density with power efficiency due to lower power and cooling requirements — ideal for space - and power-constrained enterprise data centers
- Widely accepted, proven sixth-generation technology for reliable access to demanding high performance applications.
Best-Fit Applications
- High-performance, mission-critical enterprise servers requiring 24×7 availability
- Highly reliable blade, pedestal, rack and tower servers
- Transaction-based applications, like OLTP, databases, HPC and big data analytics
- Power- and space-constrained data centers
- Compliance and data security initiatives
Compatibility
This drive is compatible with servers and workstations that accept 2.5" x 15mm SFF SAS drives.
This HDD will work in any system that does not require proprietary SAS HDDS. It has 1,171,875,000 512k data blocks which is slightly smaller capacity than other 600GB drives. For New RAID volumes only.
Specifications
| Enterprise Performance 15K HDD | |
|---|---|
| Model Number | ST600MP0036 |
| Performance | |
| Features | |
| Configuration/Reliability | |
| Power Management | |
| Environmental | |
| Physical | |
| Capacity | 600GB |
| Average Latency (ms) | 2 |
| Sustained Transfer Rate (Outer to Inner Diameter) MB/s | 315 to 215 |
| Max. Instantaneous Transfer Rate (SAS dual port) MB/s | 2,400 |
| Cache, Multi-segmented (MB) | 256 |
| Interface | SAS 12Gb/s |
| Intelligent NAND Endurance Management | Yes |
| Fast-Format Models | Yes |
| TurboBoost™ Enhanced Read Caching | Yes |
| Advanced Write Caching | Yes |
| Low Halogen | Yes |
| PowerChoice™ Idle Power Technology | Yes |
| Hot Plug Support | Yes |
| Organic Solderability Preservative | Yes |
| Digital Sensors for Humidity | Yes |
| Disk/Heads | 2/4 |
| Non-recoverable Read Errors per Bits Read, Max | 1 per 10E16 |
| Annualized Failure Rate (AFR) | 0.44% |
| Typical Op (A) +5V/+12V | 7.2 |
| Average Idling Power (W) | 5.8 |
| Average Operating Power (W) | 7.2 |
| Ambient Temperature, Operating (C°) | 5°C – 55°C |
| Ambient Temperature, Non-operating (C°) | -40°C – 70°C |
| Temperature Change Rate/Hr, Max (°C) | 20 |
| Relative Humidity, Non-condensing (max gradient 20%/hour) | 5% – 95% |
| Shock, Max. Operating: 11ms (Gs) | 40 |
| Shock, Max. Non-operating: 2 ms (Gs) | 400 |
| Vibration, Operating, <400 Hz (Gs) | 0.5 |
| Vibration, Non-operating: <500Hz (Gs) | 2.4 |
| Height(mm/in) | 15/0.591 |
| Width(mm/in) | 69.85/2.75 |
| Depth(mm/in) | 100.45/3.955 |
| Weight(lb/g) | 230/0.507 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Condition
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
Warranty
1 Year DiscTech Warranty
