Seagate ST900MP0006 900GB SAS Hard Drive
- Special Order - Call for Lead TimeSpecial Order - Call for Lead Time
This item has a variable lead time for fulfilment. Please call us to discuss. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 900GB |
| Speed: | 15K RPM |
| Interface Types: | SAS |
| Form Factor: | 2.5" SFF Server Drive |
| Electrical Interface: | SAS-3 12Gbps |
| RAM: | 256MB |
Description
Seagate ST900MP0006 900GB 2.5 inches 12Gbps 15K RPM 512n SAS HDD - Factory Recertified
Seagate ST900MP0006 900GB 2.5" 12.0 Gb/s 15000 RPM 512 Native Serial Attached SCSI Hard Disk Drive
Enterprise Performance 15K HDD
Performance You Need, Versatility You Want, Affordability You Demand
- Accelerates I/O operations and completes more transactions faster — even during peak demand
- At 900 GB, stores 50% more mission-critical data than any other 15K HDD
- Optimizes TCO with higher capacity at lower cost than high-performance alternatives
- Delivers more predictable performance (up to 27% SDR over previous generation ) while helping to protect data from corruption due to unexpected power loss
- Supports all drive formats including 512 native and a single Fast Format™ model for advanced formats (4Kn and 512e) that simplifies HDD management
- Industry-leading read caching with TurboBoost™ technology for optimum response times — perfect for OLTP applications
- Advanced Write Caching feature utilizing enhanced algorithms for the industry’s highest mission-critical storage workload performance efficiencies
- Uses traditional NAND and advanced algorithms to promote hot data and achieve performance improvement (up to 2.6× improvements over last generation )
- Enables high density with power efficiency due to lower power and cooling requirements — ideal for space - and power-constrained enterprise data centers
- Widely accepted, proven sixth-generation technology for reliable access to demanding high performance applications.
Best-Fit Applications
- High-performance, mission-critical enterprise servers requiring 24×7 availability
- Highly reliable blade, pedestal, rack and tower servers
- Transaction-based applications, like OLTP, databases, HPC and big data analytics
- Power- and space-constrained data centers
- Compliance and data security initiatives
Compatibility
This drive is compatible with laptops that accept 2.5" x 15mm SFF SAS drives.
Specifications
| Enterprise Performance 15K HDD | |
|---|---|
| Standard Model | ST900MP0006 |
| Capacity | 900GB |
| Performance | |
| Average Latency (ms) | 2 |
| Sustained Transfer Rate (Outer to Inner Diameter) MB/s | 300 to 210 |
| Max. Instantaneous Transfer Rate (SAS dual port) MB/s | 2,400 |
| Cache, Multi-segmented (MB) | 256 |
| Interface | SAS 12Gb/s |
| Intelligent NAND Endurance Management | No |
| Features | |
| Fast-Format Models | No |
| TurboBoost™ Enhanced Read Caching | No |
| Advanced Write Caching | Yes |
| Low Halogen | Yes |
| PowerChoice™ Idle Power Technology | Yes |
| Hot Plug Suppor | Yes |
| Organic Solderability Preservative | Yes |
| Digital Sensors for Humidity | Yes |
| Configuration/Reliability | |
| Disk/Heads | 3/6 |
| Non-recoverable Read Errors per Bits Read, Max | 1 per 10E16 |
| Annualised Failure Rate (AFR) | 0.44% |
| Power Management | |
| Typical Op (A) +5V/+12V | 7.6 |
| Average Idling Power (W) | 5.7 |
| Average Operating Power (W) | 7.6 |
| Enviromental | |
| Ambient Temperature, Operating (C°) | 5°C – 55°C |
| Ambient Temperature, Non-operating (C°) | -40°C – 70°C |
| Temperature Change Rate/Hr, Max (°C) | 20 |
| Relative Humidity, Non-condensing (max gradient 20%/hour) | 5% – 95% |
| Shock, Max. Operating: 11ms (Gs) | 40 |
| Shock, Max. Non-operating: 2 ms (Gs) | 400 |
| Vibration, Operating, <400 Hz (Gs) | 0.5 |
| Vibration, Non-operating: <500Hz (Gs) | 2.4 |
| Physical | |
| Height(mm/in) | 15/0.591 |
| Width(mm/in) | 69.85/2.75 |
| Depth(mm/in) | 100.45/3.955 |
| Weight(lb/g) | 230/0.507 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Condition
The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items.
The product has a manufacturer warranty for the time period specified.
Warranty
1 Year DiscTech Warranty
