Seagate Part #/MPN: ST9300603SS
DiscTech Item #: SGT-ST9300603SS-RF-OE-DEL
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Enterprise Grade
Capacity: 300GB
Speed: 10,000RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 2.5inx15mm SFF Server Drive
Sector Size: 512 / 512e
Sustained Throughput: 67 to 129
Average Seek Time: 3.6/4.2
Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps
On-Board Cache: 16MB
Compatible Systems: Dell 10th Gen. 2950 / 6950
Dell T871K / Seagate Savvio ST9300603SS 9FK066-150 T871K 10K.3 300GB 10K 6Gbps SFF Serial SCSI / SAS Hard Drive - Refurbished OEM
Dell T871K / Seagate Savvio ST9300603SS 9FK066-150 T871K 10K.3 300GB 10K 6Gbps SFF Serial SCSI / SAS Hard Drive - Refurbished OEM
Fast and then some
Seagate® Savvio® 10K.3 and Savvio 10K.3 FDE1 drives offer the best combination of enterprise performance and power efficiency, with up to 300-GB capacity for mainstream servers and external storage arrays. This third-generation Savvio drive gives you more than twice the number of drives over 3.5-inch products within the same rack configuration, and delivers a staggering 60 percent system-level performance increase. The Savvio 10K.3 and Savvio 10K.3 FDE drives are the world’s first to operate at 6-Gb/s transfer rates, which is part of the new SAS 2.0 feature set. SAS 2.0 was developed to provide additional signal and data integrity features to enable SAS to be ideally suited for use in highend network storage applications.
Lower power requirements = lower costs
The 2.5-inch footprint enables the lowest power profile of any tier-1 mission-critical drive. The Savvio 10K.3 drive with PowerTrim technology uses 67 percent less power than a 3.5-inch 15K drive. The lower power footprint of 2.5-inch drives enables lower cooling costs. The 2.5-inch drive advantages translate into greater overall value and reduced total cost of ownership to IT organizations and administrators who want to optimize their data center power and performance efficiency.
Government-grade security available
Delivering on the Seagate commitment to add security features throughout its product portfolio, the Savvio 10K.3 FDE drive is offered with selfencrypting FDE technology and will provide government-grade data-at-rest protection through its entire life cycle.
1 The Savvio 10K.3 FDE is available only through designated OEMs.
Alt MPN: 0C975M C975M 9FK066-051 9FK066-150 A248482 T871K 0T871K
Compatibility:
All SAS compatible servers including (This list is not all inclusive):
Dell PowerEdge 1900, 1950, 1955, 2900, 2950, 6900, 6950 Servers and MD1120 Storage Arrays.
Compaq/HP Proliant:
BL20p G4, BL460c, BL465c, BL480c, DL360 G4p, DL360 G5, DL380 G4, DL380 G5, DL385, DL385 G2, DL580 G3, DL580 G4, DL585, DL585 G2, ML350 G5, ML370 G4, ML370 G5, ML570 G3, ML570 G4
| Specifications | |
|---|---|
| Model number | ST9300603SS |
| Model Name | Savvio 10K.3 |
| Formatted Capacity | 300 Gbytes |
| Rotational Speed | 10,000 rpm |
| Default Buffer (cache) Size | 16 Mbytes |
| Number of Discs (physical) | 2 |
| Number of Heads (physical) | 4 |
| Performance | |
| External (I/O) Transfer Rate (max) | 600 MBytes/sec |
| Sustained Transfer Rate | 67 - 129 MBytes/sec |
| Average Seek Time, Read | 3.6 msec typical |
| Average Seek Time, Write | 4.2 msec typical |
| Track-to-Track Seek, Read | 0.2 msec typical |
| Track-to-Track Seek, Write | 0.3 msec typical |
| Average Latency | 3 msec |
| Physical | |
| Form Factor(width) | 2.5-inch |
| Form Factor(height) | .583-inch |
| Height | 14.8 mm |
| Width | 70 mm |
| Length | 100.5mm |
| Weight | 0..227 kg |
| Electrical | |
| Power (Typical) | .35 amps |
| Environmental | |
| Max Operating Shock (2-msec) | 60 Gs |
| Max Nonoperating Shock (2-msec) | 300 Gs |
| Operating Vibration (max) | .5 Gs |
| Nonoperating Vibration (max) | 2.4 Gs |
| Operating Temperature (max) | 55 deg C |
| Operating Temperature (min) | 5 deg C |
| Nonoperating Temperature (max) | 70 deg C |
| Nonoperating Temperature (min) | -40 deg C |
| Acoustical | |
| Nonrecoverable Read Errors | 1 per 10^16 bits read |
| Supports S.M.A.R.T. | Yes |
Click here to view the manufacturer's item description/brochure
Alternate MPNs: 0C975M C975M 9FK066-051 9FK066-150 A248482 T871K 0T871K
Weight: 0.5 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
