Western Digital Part #/MPN: WD3001BKHG
DiscTech Item #: WDC-WD3001BKHG-RF-OE-DEL
- RefurbishedCondition Levels Explained
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Enterprise Grade
Capacity: 300GB
Speed: 10,000RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 2.5inx15mm SFF Server Drive
Sector Size: 512 / 512e
Sustained Throughput: 204
Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps
On-Board Cache: 32MB
Western Digital Xe WD3001BKHG 300GB 10K 6Gbps 2.5" SFF Serial Attached SCSI Hard Drive - Refurbished OEM
Western Digital Xe WD3001BKHG 300GB 10K RPM 6Gbps 2.5inch Small Form Factor Serial Attached SCSI Hard Drive
Ultra-fast SAS storage
WD S25 delivers 6 Gb/s transfer rates, sustained sequential data rates up to 204MB/s.
Industry’s highest reliability rating
With a field-tested MTBF of up to 1.75 million hours, these high performance drives are perfect for enterprise server and enterprise storage applications. (BKHG models)
Low power consumption
This 2.5-inch SAS drive requires less than 8 watts to operate.
Ultra-cool operation
The small form-factor, 70 percent smaller than 3.5-inch drives, allows more system airflow resulting in lower cooling costs.
Rotary Acceleration Feed Forward (RAFF)
Optimizes operation and performance when the drives are used in vibrationprone, multi-drive chassis.
NoTouch ramp load technology
The recording head never touches the disk media ensuring significantly less wear to the recording head and media as well as better drive protection in transit.
Environmentally conscious
In addition to being ROHS compliant, these drives also incorporate a halogen free design.
Dell MPN : CWHNN 0CWHNN
Compatibility:
This drive is compatible with any server that accepts small form factor (SFF) SAS hard drives
| Specfications | 300 GB |
| Model Number | WD3001BKHG |
| Interface | SAS 6 Gb/s |
| Formatted capacity | 300 GB |
| User sectors per drive | 586,072,368 |
| SCSI command queuing | Yes |
| Form Factor | 2.5-inch |
| Performance | |
| Data transfer rate (max) | |
| Buffer to host | 6 Gb/s |
| Host to/from drive (sustained) | 204 MB/s |
| Cache (MB) | 32 |
| Rotational speed (RPM) | 10,000 |
| Average drive ready time (sec) | 13 |
| Reliability/Data Integrity | |
| Load/unload cycles | 600,000 |
| Non-recoverable read errors per bits read | <10 in 10^17 |
| MTBF (hours) | 1,750,000 |
| Power Management | |
| 12VDC (A, max) | 1.6 |
| Average power requirements (W) | |
| Sequential read/write | 5.3 /7.0 |
| Random read/write | 6.4 |
| Idle | 5.2 |
| Environmental Specifications | |
| Temperature (C) | |
| Operating | 5 to 55 |
| Non-OPERATING (2 ms) | -40 to 70 |
| Average acoustics (dBA) | |
| Idle mode | 28 |
| Performance seek mode | 34 |
| Physical Dimensions | |
| Height (in./mm, max) | 0.59/15 |
| Length (in./mm, max) | 3.94/100 |
| Width (in./mm,) | 2.75/69.85 |
| Weight (lb./kg) | 0.51/0.23 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: CWHNN 0CWHNN
Weight: 1 lb
Warranty: 1 Year DiscTech
Refurbished
These products have had NO problems or failures, they merely have some usage. The product has been professionally returned to excellent condition. These items have been fully tested, formatted (if appropriate) &repackaged. Hard drives are fully vetted for surface defects and wear, only healthy disks are approved for resale to our customers. Please see our refurbishing process for more details. Watch a video about our refurbishing process
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
