Dell 990FD / Toshiba AL13SXB600N 15K SFF SAS HDD

Toshiba Part #/MPN: AL13SXB600N

DiscTech Item #: TOS-AL13SXB600N-BN-OE-DEL

  • Inventory Is Inbound
    Stock Levels

    This item is currently on order with our supplier and is expected to arrive soon.


Enterprise Grade

Capacity: 600GB

Speed: 15,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps

On-Board Cache: 64MB

Compatible Systems: Dell 11th Gen. R710/T610

Dell 990FD / Toshiba AL13SXB600N 600GB 15000 RPM 6.0Gbps SFF SAS HDD - Brand New OEM

Toshiba AL13SXB600N 600 GB 15,000 RPM 6 Gbps SAS 2.5" Small Form Factor Serial Attached SCSI Hard Disk Drive

Delivers Toshiba's highest Mission Critical disk drive performance and reliability with capacities up to 600GB in a power-saving, low-latency 2.5-inch form-factor.

600, 450 and 300GB models in a space-efficient, power-saving 2.5inch form-factor

15,000rpm performance and industry-leading low latency (2.0ms)

512 native sector length support in all capacities for optimum compatibility

Mission Critical performance and data reliability

ALT MPN: 990FD, 0990FD, HDEAE00DAA51


This tray is compatible with the Dell Poweredge T310, R310, T320, R320, R415, T410, T420, R420, R510, R515, R520, T620, R610, T610, R620, R710, T710, R720, R720XD R820, M600, M605, M610, M610x,M710, M710HD, R715, R810, R815, M805, M905, M910, R910, M915, M1000e, Dell Powervault: MD1120, MD1220, MD3220i, MD3620i, MD3620f

Drive specification


Formatted Gbytes


Bytes per sector


Spindle speed (RPM)


I/O data transfer rate (MBps)


Cache buffer

64 MB

Interface Type

6.0Gbps SAS

Seek time (read / write) ms

7.5 / 8.5

Sustainted Data Transfer Rate


Dimensions (HxLxW) mm

15 / 100.45 / 70.1


0.200 kg

Operating Shock (Read)

25G, 2ms

Temperature - Operating

5C -60C

Temperature - Non-operating

-40C - 70C

Current Requirements 12VDC (Read/Write, Idle)

10.8w / 8.0w

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: 0990FD 990FD HDEAE00DAA51

Weight: 0.5 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
