Toshiba Part #/MPN: AL14SEB090N
DiscTech Item #: TOS-AL14SEB090N-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- In Stock:23Need more?Stock Levels
This stock level is real time and accurate. This quantity is available for same-day shipment. Larger quantities can take up to a week to ship. Call us for larger quantities that you need urgently.
Enterprise Grade
Capacity: 900GB
Speed: 10,000RPM
Interface Types: SAS Serial Attached SCSI
Form Factor: 2.5inx15mm SFF Server Drive
Sector Size: 512 / 512e
Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps
On-Board Cache: 128MB
Toshiba AL14SEB090N 900GB 2.5-Inch SFF 12Gbps 10K RPM 512n SAS Enterprise Hard Drive - Brand New
Toshiba AL14SEB090N 900GB 2.5" SFF / Small Form Factor 12.0 Gb/s 10,000 RPM 512n / 512 Native SAS / Serial Attached SCSI Enterprise HDD / Hard Drive - Brand New
Alt MP/N: HDEBF02GEA51
The AL14SEB-N Enterprise Performance HDD models combine the performance of 10,500rpm spindle speed with capacities up to 1200 GB in a compact, power efficient 2.5-inch form factor. Engineered for mission critical IT operations, the AL14SEBxxxN models support 12.0 Gbit/s SAS and provide 512 Byte per sector native format required for legacy applications and operating environments while delivering sustained transfer rates reaching 196 MiB/s. In addition, the AL14SEB-N Series helps to reduce operating costs by improving access time and reducing power consumption when compared with legacy 3.5-inch Enterprise Performance HDD models
Key Features
- Industry Standard 2.5-inch 15mm Height Form Factor
- 1.2 TB, 900 GB, 600 GB, 450 GB and 300 GB Capacity Models
- 10,500 rpm Rotational Performance or low latency
- Dual-Port 12.0 Gbit/s SAS Interface
- MTTF of 2,000,000 hours
- 24/7 Mission Critical Workload Performance and Data Reliability
Applications
- Hybrid and Mainstream Storage Arrays
- Mid-Range Volume Servers
- Blade and Rack mount Servers
- Mission-Critical Systems
- Edge Servers and Content Delivery Infrastructure
Compatibility:
This drive is compatible with servers and arrays that accept 2.5” 15mm SFF SAS drives
| Toshiba AL14SEB-N Series | |
|---|---|
| Model Number | AL14SEB090N |
| Main Specification | |
| Interface | SAS-3.0 (12.0 Gbit/s , 6.0 Gbit/s , 3.0 Gbit/s , 1.5 Gbit/s) |
| Formatted Capacity | 900GB |
| Performance | |
| Interface Speed | 12.0 Gbit/s Max. |
| Rotation Speed | 10,500 RPM |
| Average Latency Time | 2.86 ms |
| Buffer Size | 128 MiB |
| Logical Data Block Length | |
| HOST | 512 to 528 B ( fixed length ) |
| DISK | 512 to 528 B ( fixed length ) |
| Supply Voltage | |
| Allowable Voltage | 5 V ± 5% 12 V ± 5 % |
| Power Consumption | |
| MTTF | 2,000,000 hours |
| Low Power Idle | 4.0 W Typ. |
| Reliability | |
| Non-recoverable Error Rate | 10 errors per 10¹7 bits read |
| Mechanical Specifications | |
| Height | 15.0 mm ± 0,5 mm Max. |
| Width | 69.85 mm ±0.25 mm Max |
| Length | 100.45 mm Max |
| Weight | 230 g Max. |
| Environmental Limits | |
| Operating Temperature | 5 °C to 55 °C |
| Non-Operating Temperature | - 40 °C to 70 °C |
| Operating Humidity | 5 % to 95 % R.H. (No condensation) |
| Non-Operating Humidity | 5 % to 95 % R.H. (No condensation) |
| Operating Shock | 980 m/s2 { 100 G } ( 1 ms duration ) |
| Non-Operating Shock | 3,920 m/s2 { 400 G } ( 2 ms duration ) |
| Operting Vibration | 9.8 m/s2 { 1.0 G } ( 20 to 300 Hz ) |
| Non-Operating Vibration | 49 m/s2 { 5.0 G } ( 20 to 300 Hz ) |
| Operating Altitude | -305 m to +3,048 m { -1,000 to +10,000 feet } |
| Non-Operating Altitude | -305 m to +12,192 m { -1,000 to +40,000 feet } |
| Environmental Feature | |
| RoHS | Compatible |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HDEBF02GEA51
Weight: 1 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
