Toshiba MG03ACA100 1TB 7.2K Enterprise SATA Hard Drives
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 1TB |
| Speed: | 7.2K RPM |
| Interface Types: | SATA |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SATA 600 - 6Gbps |
| RAM: | 64MB |
Description
Toshiba MG03ACA100 1TB / 1000GB 6Gbps 7.2K RPM Enterprise SATA Hard Drive - Brand New
Toshiba MG03ACA100 1TB / 1000GB 6.0Gbps 7,200 RPM Enterprise SATA Hard Drive - Brand New
The Toshiba MG03ACA/MG03SCA series HDDs are designed to support enterprise applications where reliability, high capacity, and performance are required. The series is ideally suited for data archives and digital records storage, entry and business critical server and storage systems, disk backup systems—including remote sites for data protection and business continuity, and tiered virtual infrastructure for public and private cloud deployments (IaaS and PaaS).
The optional SATA self-encrypting (SED) models support fast and secure cryptographic erase using both the latest T13 SANITIZE crypto-scramble protocol and the older T13 ATA Security Erase command protocol. The optional SAS SED models support both the T10 SANITIZE crypto-erase feature and the Trusted Computing Group Enterprise Security Sub-Classification protocols. These proven, industry-standard security technologies support “nearly instantaneous” cryptographic-erase of user data to enable fast and secure device retirement or redeployment. Using SEDs can eliminate the need for lengthy data overwrite cycles and reduce IT department expenses associated with secure data destruction and device sanitization.
The series leverages the expertise and history of Toshiba in enterprise class storage and offers similar features as traditional enterprise-class drives including 24 x 7 operation and Error Correction (ECC). The MG0ACA SATA interface models support the ATA Enhanced Secure Cryptographic Erase function.
Highlights
- Lowest Cost Per GB Enterprise Storage Option
- 6 Gb/sec SAS and 6 Gb/sec (SATA) Interfaces
- Error Correction (ECC)
- Optional Self-Encrypting (SED) Models
ALT. PN: HDEPQ03GEA51
Compatibility
This drive is compatible with any server that accepts 3.5"x1" (LFF) SATA drives.
Specifications
| Specifications | |
|---|---|
| Model Number | MG03ACA100 |
| Formatted capacity | 1TB / 1000GB |
| Performance | |
| Buffer Size | 64MiB FIFO ring buffer |
| Rotation Speed | 7,200 RPM |
| Average Latency Time | 4.17ms |
| Average seek time(read) | 8.5ms |
| Average seek time(write) | 9.5ms |
| Sustained transfer rate (Max.) | 155 MB/s |
| Reliability | |
| Load/Unload | 600,000 times |
| MTTF | 1,200,000 hours |
| Operating condition | 24 hours/day, 7day/week, 100% duty |
| Supply Voltage | |
| Allowable Voltage | 5V±5% , 12V±5% |
| Power Consumption | |
| Read/Write | 11.3 watts |
| Low power idle | 6.0 wat |
| Physical Size | |
| Dimensions (W) x (D) x (H) | 101.6 mm x 147 mm x 26.1 mm |
| Weight | 720g (Max.) |
| Temperature | |
| Operating | 5 ~ 55°C |
| Non-operating | -40° ~ 70°C |
| Vibration/Shock | |
| Vibration (op) | 7.35m/s2 (0.75G, 5~300Hz) 2.45m/s2 (0.25G, 300~500Hz) |
| Vibration (non-op) | 49 m/s2 (5G, 5~500Hz) |
| Shock (op) | 686 m/s2 (70G) 2ms |
| Shock (non-op) | 2,940 m/s2 (300G) 2ms |
| Acoustics | |
| Acoustics | 31 dB |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: HDEPQ03GEA51
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
