Toshiba MG04SCA300A 3TB 3.5in LFF SAS Drive

(0) No Reviews Yet

Toshiba Part #/MPN: MG04SCA300A

DiscTech Item #: TOS-MG04SCA300A-BN-OE


$79.00
$79.00

Enterprise Grade

Capacity: 3TB

Speed: 7,200RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 4Kn

Sustained Throughput: 185 MBps

Average Seek Time: 8.5 ms

Electrical Interface: SAS-2 Serial Attached SCSI v2 - 6.0Gbps

On-Board Cache: 64MB

Toshiba MG04SCA300A 3TB 4Kn 3.5in LFF  7.2K 6.0Gbps Serial SCSI / SAS Hard Drive - Brand New

Product info

The new reliable nearline model features a top storage capacity of up to 3TB in a 3.5-inch form factor and leading-edge 6Gb/sec SAS interface. Intended for 24 x 7 operation, the MG04SCA300A also includes features that are critical to business operations such as enhanced Error Correction Code (ECC), Anti Rotational Vibration (RV) technology for multi-drive systems, and enhanced power condition state technology. The MG04SCA300A provides a flexible and cost effective storage solution for enterprise applications including entry-level servers, storage arrays, RAID systems and digital video systems.

Product Features

  • SAS-2.0 Interface (1.5 / 3.0 / 6.0 Gb/s)
  • Up to 3TB Capacity with 4Kn Bytes per Sector
  • 24x7 operation
  • Enhanced Power Condition State Technology
  • Rotational Vibration Technology for Multi-drive Systems
Alt Pt# HDEPE22GEA51

    Compatibility:

    This drive is compatible with any of our SAS drive trays and any of our SAS controllers.

    Specifications
    Formatted storage capacity3000 GByte / 4Kn Bytes per Sec
    Seek time (track to track)
    • Read: 0.8 ms
    • Write: 1.0 ms
    Seek time (average)
    • Read: 8.5 ms
    • Write: 9.5 ms
    Seek time (max.)
    • Read: 15.1 ms
    • Write: 16.1 ms
    Average latency time4.17 ms
    Rotational speed7,200 rpm
    InterfaceSAS-2

    1.5, 3.0, 6.0 Gbps
    Data buffer size64MiB FIFO ring buffer MByte
    Form factor3.5 inch
    Height26.1 mm
    Width101.6 mm
    Depth147 mm
    Weight (max.)800 g
    Ambient temperature (operating)
    • From +5 °C to +55 °C
    Ambient temperature (non-operating)
    • From -40 °C to +70 °C
    Vibration (operating)0.75G (5 - 300 Hz) G
    Vibration (non-operating)5G (5 - 500 Hz) G
    Shock (operating)2 ms: 70 G
    Shock (non-operating)2 ms: 300 G
    AcousticsReady: 31 dB

    Click here to view the manufacturer's item description/brochure

    ROHS Compliant

    Alternate MPNs: HDEPE22GEA51

    Weight: 1.8 lb

    Warranty: 1 Year DiscTech

    Brand New

    Condition Levels Explained

    The product is brand new.

    1 Year DiscTech Warranty

    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty
