Western Digital Part #/MPN: HUS728T8TALE6L4
DiscTech Item #: WDC-HUS728T8TALE6L4-NP-OE-DEG
- New Pull
- Warranty:1 Year DiscTech
- Low Stock:Call for ETA
Enterprise Grade
Capacity: 8TB
Speed: 7.2K RPM
Interface Types: SATA
Form Factor: 3.5" LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 243/255
Average Seek Time: 8.0/8.6
Electrical Interface: SATA 600 - 6Gbps
On-Board Cache: 256GB
Western Digital HUS728T8TALE6L4 / 0B36404 / 0B36474 Ultrastar DC HC320 8TB 3.5" LFF 6Gbps 7.2K 512e Enterprise SE SATA HDD - New Pull OEM
Western Digital HUS728T8TALE6L4 / 0B36404 / 0B36474 Ultrastar DC HC320 8TB 3.5" LFF 6Gbps 7.2K 512e Enterprise SE SATA HDD - New Pull OEM
DP/N: 7MJCV 07MJCV
HGST Ultrastar DC HC320
3.5-Inch Data Center Hard Disk Drive
Economics and Access Speed: Key Requirements for Low Capacity HDDs in the Data Center
As the industry evolves to develop purpose-built solutions for growing data storage requirements, IT managers continue to rely on lower capacity drives that are economical to acquire, yet deliver quick and reliable data access for traditional data center applications. Designed to handle workloads up to 550TB per year, Ultrastar® DC HC320* is an 8TB1 HDD that helps address economic and access requirements of many traditional IT workloads. Low capacity drives also help address architecture limitations. The Ultrastar DC HC320 is designed for traditional storage and server applications as well as distributed and scalable computing, including block and file storage architectures, providing fast 7,200 RPM performance and lower acquisition cost to help ease budget constraints. Ultrastar DC HC320 is offered with either 6Gb/s SATA or 12Gb/s SAS interface in a choice of 512e or 4Kn formats.
Technology Innovation Delivers Efficiency and Performance for Traditional IT Systems
Ultrastar DC HC320 is based on a proven 5-disk air platform design that uses conventional magnetic recording (CMR) technology in a 3.5-inch large form factor. Compared to the prior generation, Ultrastar 7K6000, the DC HC320 delivers 33% more capacity, up to 12% performance boost and uses slightly larger-diameter media. It features a secondgeneration, dual-stage micro actuator to enhance head positioning accuracy for better drive performance. Write performance gains are also supported by Western Digital’s media cache architecture, a diskbased caching technology that provides a large cache area on the disk, which also improves reliability and data integrity during unexpected power loss. Finally, the addition of flash-based non-volatile cache (NVC) on both SATA and SAS models helps improve write performance. The Ultrastar DC HC320 also includes a Rebuild Assist feature, which helps dramatically reduce RAID rebuild times and maintain system performance during the rebuild process. Learn more in our Rebuild Assist technical brief.
Data Security with Trusted Quality, Reliability
Compliance and privacy requirements drive the need for increased data security. Ultrastar DC HC320 helps protect data from unauthorized use by offering security and encryption options. SAS models offer hardwarebased encryption options, including a Trusted Computing Group (TCG) Enterprise_A, TCG with FIPS 140-2 certification, Level 2. The Ultrastar DC HC320 extends Western Digital’s long-standing tradition of reliability leadership with a 2M-hour MTBF2 rating.
Features & Benefits
Capacity
- Feature / Function
- 8TB
- Advanced Format
- Benefits
- Lower capacity point for traditional IT workloads and applications
- Enables higher capacity and reliability
Performance
- Feature / Function
- Non-volatile cache (NVC)
- Up to 255MB/s transfer rate
- Benefits
- Improved write performance and write splice protection
- Up to 12% faster than Ultrastar 7K6000
Reliability
- Feature / Function
- Dual-stage Micro Actuator
- 2M hours MTBF and 0.44% AFR
- Benefits
- Better head positioning and rotational vibration robustness
- One of the highest reliability ratings for air-filled Capacity Enterprise HDDs
Highlights
- Excellent random and sequential performance
- 8TB capacity point supports traditional IT systems
- Sustained transfer rate up to 255MB/s
- Choice of 12Gb/s SAS or 6Gb/s SATA
- Advanced Format 4Kn and 512e models
- Self-Encrypting Drive (TCG SAS) options
Applications & Workloads
- Distributed file systems, like Apache Hadoop® , to support Big Data analytics
- Direct & Network Attached Storage (DAS & NAS)
- RAID arrays
Compatibility:
This drive is compatible with any server that accepts 3.5in x 1.0in (LFF) SATA drives
Ultrastar DC HC HC320 SATA Hard Drive | |
Model Number | HUS728T8TALE6L4 |
Alt Model Number | 0B36404 |
Data Security Mode | Secure Erase |
Configuration | |
Interface | SATA 6Gb/s |
Capacity (TB) | 8TB / 8,000 |
Form Factor | 3.5-inch |
Format Sector Size (bytes) | 512e: 512 |
Max. Areal Density | 834 |
Performance | |
Data Buffer (MB) | 256 |
Rotational Speed (RPM) | 7200 |
Latency Average (ms) | 4.16 |
Interface Transfer Rate | 600 |
Sustained Transfer Rate |
|
Seek Time | 8.0/8.6 |
Reliability | |
Error Rate | 1 in 10^15 |
Load/Unload Cycles | 600,000 |
MTBF | 2m hours |
Annualized Failure Rate | 0.44% |
Availability | 24x7 |
Acoustics | |
Idle/Operating (Bels, typical) | 2.9/3.6 |
Power | |
Requirement | +5 VDC, +12VDC |
Operating (W) | 8.8 |
Idle (W) | 7.4 |
Physical size | |
z-Height (mm) | 26.1 |
Dimensions | 101.6 (+/- -0.25) x 147 |
Weight | 715 |
Environmental (Operating) | |
Ambient Temperature | 5° to 60° C |
Shock | 70 |
Vibration | 0.67 (XYZ) |
Environmental (Non-Operating) | |
Ambient Temperature | -40° to 70° C |
Shock | 300 |
Vibration | 1.04 (XYZ) |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Alternate MPNs: 0B36404 0B36474 7MJCV 07MJCV
Weight: 1.8 lb
Warranty: 1 Year DiscTech
New Pull
1 Year DiscTech Warranty
