Western Digital Re WD2503ABYZ 250GB Enterprise 3.5" SATA Hard Drive

- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 5 Year ManufacturerWarrantyProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
| Capacity: | 250GB |
| Speed: | 7.2K RPM |
| Interface Types: | SATA |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SATA 600 - 6Gbps |
| RAM: | 64MB |
Description
Western Digital Re WD2503ABYZ 250GB 7.2K 6Gb/s Enterprise 3.5" SATA Hard Drive - Brand New
WD Re Datacenter SATA Hard Drives | Dual processor |
RAFF™ | IntelliSeek™ |
Multi-axis shock sensor | RAID-specific, time-limited error recovery (TLER) |
NoTouch™ ramp load technology | Thermal extended burn-in test |
Third generation dynamic fly height | 24x7 reliability |
Compatibility
This drive is compatible with any SATA hot swap trays and controllers.
Specifications
| Specifications | |
| Model number | WD2503ABYZ |
| Interface | SATA 6 Gb/s |
| Formatted capacity | 251 GB |
| User sectors per drive | 490,350,672 |
| Native command queuing | Yes |
| SATA latching connector | Yes |
| Form factor | 3.5-inch |
| Performance | |
| Max Data transfer rate | 6 Gb/s |
| Cache (MB) | 64 |
| Rotational speed (RPM | 7200 |
| Average drive ready time (sec) | 14 |
| Configuration/Organization | |
| Heads/disks | 1/1 |
| Bytes per sector (STD) | 512 |
| Reliability/Data Integrity | |
| Load/unload cycles | 600,000 |
| Non-recoverable read errors per bits read | <1 in 1015 |
| Limited warranty (years) | 5 |
| Power Management | |
| 12VDC (A, max) | 2.25 |
| Average required wats Read/Write | 6.5 / 6.4 |
| Average required wats Idle | 4.4 |
| Average required wats Standby | 0.8 |
| Average required wats Sleep | 0.8 |
| Environmental Specifications | |
| Operating Temperature (°C) | 5 to 55 |
| Non-operating Temperature (°C) | -40 to 70/td> |
| Shock (Gs) Operating (2 ms, read/write) | 30 |
| Shock (Gs) Operating (2 ms, read) | 65 |
| Shock (Gs) Non-operating (2 ms) | 350 |
| Average acoustics (dBA) Idle mode | 27- |
| Average acoustics (dBA) Performance seek mode | 30 |
| Average acoustics (dBA) Quiet seek mode | 29 |
| Physical Dimensions | |
| Height (in./mm, max) | 1.028/26.1 |
| Length (in./mm, max) | 5.787/147 |
| Width (in./mm, ± .01 in.) | 4/101.6 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 1.8 lb
Warranty: 5 Year Manufacturer
Condition
The product is brand new.
Warranty
5 Year Manufacturer Warranty
