Western Digital Part #/MPN: WD2004FBYZ
DiscTech Item #: WDC-WD2004FBYZ-BN-OE
- Brand NewCondition Levels Explained
The product is brand new.
- Warranty:1 Year DiscTechProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
Enterprise Grade
Capacity: 2TB
Speed: 7,200RPM
Interface Types: SATA
Form Factor: 3.5inx1.0in LFF Hard Drive
Sector Size: 512 / 512e
Sustained Throughput: 200
Electrical Interface: SATA 600 - 6.0Gbps
On-Board Cache: 128MB
Western Digital WD2004FBYZ WD Re 2TB 3.5" 6Gbps 7.2K RPM 512n Enterprise SATA HDD - Brand New
Western Digital WD2004FBYZ WD Re 2TB / 2000GB 3.5" 6.0 Gb/s 7200 RPM 512 Native Enterprise Serial Attached Technology Attachment Hard Disk Dive - Brand New
WD Re
Datacenter Capacity HDD
Performance-optimized high-capacity storage for high-intensity applications.
Advanced drive technology that delivers consistent high performance in a multitude of applications, and with up to ten times the workload capability of desktop drives, the WD Re drive is the workhorse of WD’s datacenter portfolio. The WD Re drive is perfect for high-availability storage arrays that demand a robust storage device, and this drive’s high performance, capacity, and reliability make it ideal for data warehousing/mining and high-performance computing. The WD Re uses a SATA interface to provide maximum flexibility and compatibility.
Product Benefits
High capacity nearline drive
Multiple capacities to suit even the most demanding datacenter, enterprise server, or cloud storage needs.
Designed for high-intensity applications
Designed to handle workloads up to 550TB per year – among the highest workload capability of any 3.5-inch hard drive – delivering both performance and reliability to any datacenter environment.
Vibration Protection
Enhanced RAFF™ technology includes sophisticated electronics to monitor the drive and correct both linear and rotational vibration in real time. The result is a significant performance improvement in high vibration environments over desktop drives.
Dual actuator technology
A head positioning system with two actuators that improves positional accuracy over the data track(s). The primary actuator provides coarse displacement using conventional electromagnetic actuator principles. The secondary actuator uses piezoelectric motion to fine tune the head positioning to a higher degree of accuracy.
Multi-axis shock sensor
Automatically detects the subtlest shock events and compensates to protect the data.
RAID-specific, time-limited error recovery (TLER)
Reduces drive fallout caused by the extended hard drive error-recovery processes common to desktop drives.
Designed for quality and reliability
With 2.0 million hours MTBF, these drives ensure one of the highest level reliability ratings for high-capacity enterprise storage needs.
Thermal extended burn-in test
Each drive is put through extended burn-in testing with thermal cycling to ensure reliable operation.
NoTouch™ ramp load technology
The recording head never touches the disk media ensuring significantly less wear to the recording head and media as well as better drive protection in transit.
Dynamic fly height technology
Each read-write head’s fly height is adjusted in real time for optimum reliability.
Applications
Online Analytical Processing (OLAP), data warehousing/mining, high-performance computing, high-end NAS/SAN and surveillance systems, and high-availability cloud storage arrays.
The WD Advantage
WD puts datacenter products through extensive Functional Integrity Testing (F.I.T.) prior to any product launch. This testing ensures our products consistently meet the high quality and reliability standards of the WD brand. Following a FIT test the Enterprise System Group (ESG) testing validates interoperability with HBAs, operating systems, and drivers, to ensure an even greater level of quality, reliability, and peace of mind.
WD also has a detailed Knowledge Base with helpful articles and software utilities. Our customer support lines have long operational hours to ensure you get the help you need when you need it. Our toll-free customer support lines are here to help or you can access our WD Support site for additional details.
Compatibility:
This drive is compatible with any server that accepts 3.5inx1.0in SATA Drive.
| WD Re | |
|---|---|
| 512 native model number | WD2004FBYZ |
| Technical Specifications | |
| Logical/Physical bytes per sector | 512/512 |
| Formatted capacity | 2TB / 2000GB |
| Interface | SATA 6Gb/s |
| 512n/512e user sectors per drive | 3,907,029,168 |
| Native Command Queuing | Yes |
| Form Factor | 3.5-inch |
| RoHS compliant | Yes |
| Performance | |
| Data transfer rate (max) | |
| Cache (MB) | 128 |
| Performance Class | 7200 RPM Class |
| Reliability/Data Integrity | |
| Load/unload cycles | 600,000 |
| Non-recoverable read errors per bits read | <1 in 10^15 |
| MTBF (hours) | 2,000,000 |
| AFR (%) | 0.44 |
| Power Management | |
| Average power requirements (W) | |
| Environmental Specifications | |
| Temperature (°C) | |
| Shock | |
| Acoustics (dBA) | |
| Physical Dimensions | |
| Height (in/mm, max) | 1.028/26.1 |
| Length (in/mm, max) | 5.787/147 |
| Width (in/mm, ± .01 in) | 4/101.6 |
| Weight ((lb/kg, ± 10%) | 1.41/0.64 |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Brand New
The product is brand new.
1 Year DiscTech Warranty
The product has a DiscTech warranty for the time period specified. View our limited warranty
