Western Digital AV-GP WD20EURS SATA Hard Drive
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
| Capacity: | 2TB |
| Speed: | 7.2K RPM |
| Interface Types: | SATA |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SATA 300 - 3Gbps |
| RAM: | 64MB |
Description
Western Digital AV-GP WD20EURX 2000GB / 2TB 7.2K SATA 3.5" Hard Drive - Brand New
WD AV-GP SATA hard drives store more hi-def audio and video than ever before – up to 3 TB. They are optimized with SilkStream™ technology to capture data from up to 12 simultaneous HD video streams. And with 24x7 operation, low temperature, and best-in-class reliability, WD AV-GP hard drives are ideal for DVR/PVR and video surveillance applications. 3-year limited warranty.
MDL: WD20EURX-63T0FY0
Compatibility
Tested for compatibility in a broad range of AV products including set top boxes, DVR/PVR, and mainstream video surveillance systems. For drives with greater than 2.19 TB capacity, compatibility is selective to PVRs and surveillance systems that are compatible with hard drives exceeding 2.19 TB.
Specifications
| Performance Specifications | ||
Rotational Speed | IntelliPower * | |
Buffer Size | 64 MB | |
Acoustics (Sone) | < 1 | |
| ||
Transfer Rates | ||
Buffer To Host (Serial ATA) | 3 Gb/s (Max) | |
Host to/from drive (Sustained) | 130 MB/s (Max) | |
Physical Specifications | ||
Formatted Capacity | 2,000,398 MB | |
Capacity | 2 TB | |
Interface | SATA 3 Gb/s | |
User Sectors Per Drive | 3,907,029,168 | |
| ||
| Physical Dimensions | ||
English | ||
Height | 1.028 Inches | |
Depth | 5.787 Inches | |
Width | 4.00 Inches | |
Weight | 1.40 Pounds | |
| ||
Metric | ||
Height | 26.1 mm | |
Depth | 147 mm | |
Width | 101.6 mm | |
Weight | 0.64 kg | |
| ||
| Environmental Specifications | ||
Shock | ||
Operating Shock (Read) | 65G, 2 ms | |
Non-operating Shock | 250G, 2 ms | |
| ||
Acoustics | ||
Idle Mode | 24 dBA (average) | |
Seek Mode 3 | 25 dBA (average) | |
| ||
Temperature (English) | ||
Operating | 32° F to 140° F | |
Non-operating | -40° F to 158° F | |
| ||
Temperature (Metric) | ||
Operating | -0° C to 60° C | |
Non-operating | -40° C to 70° C | |
| ||
| Electrical Specifications | ||
Current Requirements | ||
Power Dissipation | ||
| 4.50 Watts | |
| 4.00 Watts | |
| 0.70 Watts | |
| 0.70 Watts | |
Click here to view the manufacturer's item description/brochure
Alternate MPNs: WD20EURX-63T0FY0
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
