Fujitsu MAX3073RC SAS Hard Drive

FUJITSU Part #/MPN: MAX3073RC

DiscTech Item #: FUJ-MAX3073RC-BN-OE-DEL

$229.95
  • Brand New
    Condition Levels Explained

    The product is brand new.

  • Warranty:1 Year DiscTech
    Product Warranties Explained

    The product has a DiscTech warranty for the time period specified. View our limited warranty

  • Low Stock:Call for ETA
    Stock Levels

    This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.

Back
$229.95

Enterprise Grade

Capacity: 73GB

Speed: 15,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Sustained Throughput: 147

Average Seek Time: 3.3 /3.8

Electrical Interface: SAS-1 Serial Attached SCSI - 3.0Gbps

On-Board Cache: 8MB

Compatible Systems: Dell 10th Gen. 2950 / 6950

Fujitsu MAX 73.5GB 15K 3Gbps Serial Attached SCSI / SAS Hard Drive MAX3073RC - Brand New OEM

Fujitsu MAX 73.5 GB 15K 3Gbps Serial Attached SCSI / SAS Hard Drive MAX3036RC - Brand New OEM

Compatibility:

Powervault MD1000, Dell P0werEdge 2900, 2950, 1900, 1950, 6900, 6950

 Form Factor3.5-inch x 1-inch high  Mounting screws6#32UNC  Seek time (track to track)Read 0.2 / Write 0.4 milliseconds Seek time (average)3.3/3.8 milliseconds (read/write) Seek time (full track)8.0/9.0 milliseconds (read/write) Average latency time2.00 milliseconds Rotational speed15,000 RPM Data Buffer Size8 MB Recording code32/34 MEEPRML  InterfaceSAS (3Gbps)  Head positioning methodROTARY VCM  Spindle start time30 seconds typical Spindle stop time30 seconds typical Power requirement Idle (ready)11.5 W (typical) Height25.4 millimetres Width101.6 millimetres Depth146.0 millimetres Weight0.75 kg Ambient temperature (operating)5 to 55 degrees C Ambient temperature (non-operating)-40 to 70 degrees C Maximum DE surface temperature (operating)55 max deg. C Gradient15 degrees C per hour Relative humidity (operating)5 to 95 % RH (non-condensing) Relative humidity (non-operating)5 to 95 % RH (non-condensing) Maximum wet bulb29 degrees C (non-condensing) Vibration (operating)0.6mm (5 to 20 Hz)/ 1.0G (20 to 300 Hz)  Vibration (non-operating)3.1mm (5 to 20 Hz)/ 5.0G (20 to 300Hz)  Shock (operating)65G Max (2ms)  Shock (non-operating)250G Max (2ms)  Altitude (operating)3,000 metres Altitude (non-operating)12,000 metres Acoustic noise (at 1 metre idle)3.6 bels MTBF (Mean Time Between Failures)1,200,000 power on hours Component life (years)
Design life used to calculate MTBF. NOT Warranty5 years Unrecoverable errors1 per 10^15 bits read Seek errors10 per 10^8 seeks
Click here to view the manufacturer's item description/brochure

Weight: 1.8 lb

Warranty: 1 Year DiscTech
