Fujitsu MAX3073RC SAS Hard Drive
- Brand NewCondition Levels Explained
The product is brand new.
- Low Stock:Call for ETAStock Levels
This item is currently (nearly) out of stock. It may be possible to arrange fast shipment. If you need it urgently call us. Otherwise, it usually ships within 1 week.
- 1 Year DiscTechWarrantyProduct Warranties Explained
The product has a DiscTech warranty for the time period specified. View our limited warranty
$229.95
| Capacity: | 73GB |
| Speed: | 15K RPM |
| Interface Types: | SAS |
| Form Factor: | 3.5" LFF Hard Drive |
| Electrical Interface: | SAS-1 3Gbps |
| RAM: | 8MB |
Description
Fujitsu MAX 73.5GB 15K 3Gbps Serial Attached SCSI / SAS Hard Drive MAX3073RC - Brand New OEM
Fujitsu MAX 73.5 GB 15K 3Gbps Serial Attached SCSI / SAS Hard Drive MAX3036RC - Brand New OEM
Compatibility:
Powervault MD1000, Dell P0werEdge 2900, 2950, 1900, 1950, 6900, 6950
Specifications
Form Factor3.5-inch x 1-inch high
Mounting screws6#32UNC Seek time (track to track)Read 0.2 / Write 0.4 milliseconds Seek time (average)3.3/3.8 milliseconds (read/write) Seek time (full track)8.0/9.0 milliseconds (read/write) Average latency time2.00 milliseconds Rotational speed15,000 RPM Data Buffer Size8 MB Recording code32/34 MEEPRML InterfaceSAS (3Gbps) Head positioning methodROTARY VCM Spindle start time30 seconds typical Spindle stop time30 seconds typical Power requirement Idle (ready)11.5 W (typical) Height25.4 millimetres Width101.6 millimetres Depth146.0 millimetres Weight0.75 kg Ambient temperature (operating)5 to 55 degrees C Ambient temperature (non-operating)-40 to 70 degrees C Maximum DE surface temperature (operating)55 max deg. C Gradient15 degrees C per hour Relative humidity (operating)5 to 95 % RH (non-condensing) Relative humidity (non-operating)5 to 95 % RH (non-condensing) Maximum wet bulb29 degrees C (non-condensing) Vibration (operating)0.6mm (5 to 20 Hz)/ 1.0G (20 to 300 Hz) Vibration (non-operating)3.1mm (5 to 20 Hz)/ 5.0G (20 to 300Hz) Shock (operating)65G Max (2ms) Shock (non-operating)250G Max (2ms) Altitude (operating)3,000 metres Altitude (non-operating)12,000 metres Acoustic noise (at 1 metre idle)3.6 bels MTBF (Mean Time Between Failures)1,200,000 power on hours Component life (years)
Design life used to calculate MTBF. NOT Warranty5 years Unrecoverable errors1 per 10^15 bits read Seek errors10 per 10^8 seeks
Click here to view the manufacturer's item description/brochure
Mounting screws6#32UNC Seek time (track to track)Read 0.2 / Write 0.4 milliseconds Seek time (average)3.3/3.8 milliseconds (read/write) Seek time (full track)8.0/9.0 milliseconds (read/write) Average latency time2.00 milliseconds Rotational speed15,000 RPM Data Buffer Size8 MB Recording code32/34 MEEPRML InterfaceSAS (3Gbps) Head positioning methodROTARY VCM Spindle start time30 seconds typical Spindle stop time30 seconds typical Power requirement Idle (ready)11.5 W (typical) Height25.4 millimetres Width101.6 millimetres Depth146.0 millimetres Weight0.75 kg Ambient temperature (operating)5 to 55 degrees C Ambient temperature (non-operating)-40 to 70 degrees C Maximum DE surface temperature (operating)55 max deg. C Gradient15 degrees C per hour Relative humidity (operating)5 to 95 % RH (non-condensing) Relative humidity (non-operating)5 to 95 % RH (non-condensing) Maximum wet bulb29 degrees C (non-condensing) Vibration (operating)0.6mm (5 to 20 Hz)/ 1.0G (20 to 300 Hz) Vibration (non-operating)3.1mm (5 to 20 Hz)/ 5.0G (20 to 300Hz) Shock (operating)65G Max (2ms) Shock (non-operating)250G Max (2ms) Altitude (operating)3,000 metres Altitude (non-operating)12,000 metres Acoustic noise (at 1 metre idle)3.6 bels MTBF (Mean Time Between Failures)1,200,000 power on hours Component life (years)Design life used to calculate MTBF. NOT Warranty5 years
Unrecoverable errors1 per 10^15 bits read Seek errors10 per 10^8 seeksClick here to view the manufacturer's item description/brochure
Weight: 1.8 lb
Warranty: 1 Year DiscTech
Condition
Brand New
Warranty
1 Year DiscTech Warranty
