HPE 785692-001 / HGST C10K1800 0B33068 / HUC101860CSS204 SFF 600GB SAS Drive

(0) No Reviews Yet

Hitachi Part #/MPN: 0B33068

DiscTech Item #: HIT-0B33068-BN-OE-HPI


$239.00
$239.00

Enterprise Grade

Capacity: 600GB

Speed: 10,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 2.5inx15mm SFF Server Drive

Sector Size: 512 / 512e

Sustained Throughput: 129 to 224

Electrical Interface: SAS-3 Serial Attached SCSI v3 - 12.0Gbps

On-Board Cache: 128MB

HPE 785692-001 / HGST C10K1800 0B33068 / HUC101860CSS204 600GB 2.5" 12Gbps 10K RPM 512n SAS HDD - Brand New OEM

HPE 785692-001 / HGST C10K1800 0B33068 / HUC101860CSS204 600GB 2.5" 12Gbps 10K RPM 512n SAS HDD - Brand New OEM

HPE P/N: 785692-001

Ultrastar® C10K1800

Big Capacity and Performance in a Small Package
HGST delivers best-in-class capacity and performance in one small form factor hard drive. The Ultrastar® C10K1800 is a 10K RPM enterprise-class HDD that stores up to 1.8TB of data, 50% more capacity than prior generations, plus delivers best-in-class active and idle power efficiency, enabling next generation data centers to keep pace with digital data growth and improve space and power efficiencies. Data center architects can also leverage bestin-class performance on the C10K1800, achieving up to 2.5X better random write performance and 23% faster sequential performance over prior generation 2.5-inch SFF 10K RPM HDDs for demanding 24x7 enterprise workloads.

Technology Innovation
Ultrastar C10K1800 delivers unmatched performance thanks to several HGST technology innovations including media cache architecture, the industry’s fastest 12Gb/s Serial-Attached SCSI (SAS) interface and advanced format options. HGST’s media cache architecture is a disk-based caching technology, which provides a large non-volatile cache on the media resulting in improved reliability and data integrity during unexpected power loss, as well as a significant improvement in write performance even at high workloads when compared to solutions with limited NAND or flash-based NVC. The C10K1800 is the industry’s first 10K RPM drive to leverage an industry-leading 12Gb/s SAS interface, enabling very high transfer rates between host and drive. Advanced format models enable the industry’s highest 10K RPM capacity at 1.8TB with 4K native and 512 emulation to support new systems, and also offers 512 native format models to support legacy systems.

Enterprise Security and Reliability
The Ultrastar C10K1800 offers the broadest range of encryption and security options available on SAS HDDs from HGST, including Trusted Computing Group (TCG) enterprise SSC-compliant Self-Encrypting Drives (SED) which provide data protection without any performance loss, and TCG with FIPS (Federal Information Processing Standard) 140-2 certification, which adds and tamper evidence protection for the most stringent regulatory data security compliance requirements. Instant Secure Erase (ISE) models enable fast, cost-effective and secure drive repurposing and retirement. C10K1800 extends the company’s long-standing tradition of reliability leadership with a 2M hours MTBF rating.

HGST Quality and Service
The Ultrastar C10K1800 extends the long-standing HGST tradition of performance and reliability leadership. A balanced combination of new and proven technologies helps ensure high reliability and availability of customer data.

HGST drives are backed by an array of technical support and services, which may include customer and integration assistance. HGST is dedicated to providing a breadth of hard disk drive solutions to satisfy all of today’s demanding computing needs.

Highlights

  • Industry-leading 1.8TB1 capacity in a 10K RPM HDD, 50% more than previous generations
  • Best-in-class performance —2.5X faster random write —23% faster sequential
  • Advance format (4KN and 512e) and 512n models
  • 12Gb/s SAS moves more data quickly & reliably
  • 128MB cache buffer manages data efficiency
  • Advanced Power Management optimizes power consumption
  • Best-in-class power efficiency
  • 2M hours MTBF2 rating
  • Security & encryption models including ISE, TCG-SED & FIPS 140-2 certified TCG-SED

Applications/Environments

  • Tier 1 enterprise-class, high-performance servers in data centers processing hot and warm data
  • Traditional mission-critical enterprise-class servers and storage
  • HPC, databases, OLTP, and BP applications requiring high reliability and 24x7 availability
  • Enterprise-class data security environments requiring increased security & easy drive retirement
  • Power- and space-constrained, mission-critical environments


Compatibility:

This drive is compatible with laptops that accept 2.5" x 15mm SFF SAS drives.

Ultrastar® C10K1800
Model/Part No.0B33068 785692-001
Alt Model/Part No.HUC101860CSS204
Configuration
InterfaceSAS 12Gb/s
Capacity600GB
Sector size (variable, bytes/sector)512-Byte (512n)
Recording zones40
Data heads (physical)3
Data disks2
Max. areal density (Gbits/sq. in)580
Performance
Data buffer (MB)128
Rotational speed (RPM)10,520
Latency average (ms)2.85
Interface transfer rate (MB/s, max)1200
Sustained transfer rate (MB/s, typical)129 to 224
Seek time (read/write, ms, typical range)3.3-3.5 / 3.8-4.2
Reliability
Error rate (non-recoverable, bits read)1 in 10^16
MTBF (M hours)2.0
Annualized Failure Rate (AFR)0.44%
Availability (hrs/day x days/wk)24x7
Acoustics
Idle (Bels)3.4
Power
Requirements+5 VDC (+/-5%)
+12 VDC (+/-5%)
Operating, (W, typical)5.9
Idle (W)4.3
Idle efficiency (W/GB)0.0042
Physical
z-height (mm)15
Dimensions (width x depth, mm)70.1 x 100.45
Weight (g, max)227
Environmental (operating)
Ambient temperature 5o to 55° C
Shock (half-sine wave 2ms, read operation)60G
Vibration, random, no errors (G RMS 5 to 500 Hz)0.4, all axes
Environmental (non-operating)
Ambient temperature -40 to 70° C
Shock (half-sine wave 2ms, read operation)300G
Vibration, random (G RMS 5 to 500 Hz)1.5, all axes

Click here to view the manufacturer's item description/brochure

ROHS Compliant

Alternate MPNs: HUC101860CSS204 785692-001

Weight: 0.5 lb

Warranty: 1 Year DiscTech

Brand New

Condition Levels Explained

The product is brand new.

1 Year DiscTech Warranty

Product Warranties Explained

The product has a DiscTech warranty for the time period specified. View our limited warranty
