Seagate ST3300656SS SAS Hard Disk

Seagate Part #/MPN: ST3300656SS

DiscTech Item #: SGT-ST3300656SS-FR-1Y

  • Special Order - Ships in 5-10 business days
    Special Order - Ships in 5-10 business days

    This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.


Enterprise Grade

Capacity: 300GB

Speed: 15,000RPM

Interface Types: SAS Serial Attached SCSI

Form Factor: 3.5inx1.0in LFF Hard Drive

Sector Size: 512 / 512e

Electrical Interface: SAS-1 Serial Attached SCSI - 3.0Gbps

On-Board Cache: 16MB

Compatible Systems: Dell 10th Gen. 2950 / 6950

Seagate Cheetah 15K.6 ST3300656SS 300GB 15K 3.0Gbps Serial SCSI / SAS Hard Drive - Factory Refurbished

15K RPM spindle speed
Delivers more I/O's per second and faster sustained transfer rates than 10K 3.5-inch drvies, enabling the same high performance to be met with fewer drives.
Background Media Scan (BMS)
Second generation Seagate-exclusive BMS proactively scans the media for potential defects during drive idle time. It enables incipient errors to be corrected before data is lost.
Perpendicular Recording
Perpendicular recording is fundamentally superior, enabling the highest areal density with 30 percent higher performance.
Nonrecoverable Error Rate
The nonrecoverable error rate has been improved by a factor of 10.
Idle Read After Write (IRAW)
Seagate-exclusive IRAW enhances data protection by verifying-during drive idle time-that data in the drive buffer was properly written.
  • The industry's highest reliability 3.5" drive
  • 30% more IOPS and 20% faster response times than 3.5" 10K drives
Capacity (Blocks)
Sector SizeST3450856SS
ST3450056SS (FDE)
ST3300056SS (FDE)
ST3146756SS (FDE)


All SAS compatible servers including:
Dell PowerEdge 1900, 1950, 2900, 2950, 6900, 6950. PowerVault MD1000


Model NumberST3300656SS
InterfaceSAS 3Gb/s
Capacity300 GB
Areal density (avg)165 Gbits/inch2
Guaranteed Sectors585,937,500
Height (max)26.11 mm (1.028 inches)
Width (max)101.85 mm (4.010 inches)
Length (max)146.99 mm (5.787 inches)
Weight (typical)694 grams (1.53 pounds)
Spindle Speed15,000 rpm
Sustained data transfer rate171,000 null
Average latency2.0 msec
Random read seek time3.4 msec
Random write seek time3.9 msec
null300 null
MTBF1,600,000 hours
Annual Failure Rate0.55%
Unrecoverable read errors1 in 10^16
Maximum start current, AC4.06 amps
Maximum start current, DC1.78 amps
Ambient Temperature
Operating5 to55 degrees C
Nonoperating-40 to70 degrees C
Maximum operating temperature change20 degrees C per hour
Maximum nonoperating temperature change20 degrees C per hour
Operating Shock (max)25 Gs null 2 msec
Nonoperating Shock (max)300 Gs null 2 msec
Acoustics (Idle Volume)3.5 bels
Acoustics (Seek Volume)3.7 bels

Click here to view the manufacturer's item description/brochure

Weight: 1.8 lb

Warranty: 1 Year Manufacturer

Factory Refurbished
