Seagate ST373454SS 73GB SAS Hard Drive

Seagate Cheetah 15K.4 73GB 15K RPM 3Gbps Serial SAS / Serial Attached SCSI Hard Drive - Refurbished OEM

Seagate Cheetah 15K.4 73GB 15000 RPM 3.0Gbps Serial SAS / Serial Attached SCSI Hard Disk Drive - Refurbished OEM

The Cheetah 15K.4 is the best performance, lowest cost of ownership, 3.5-inch disc drive. It enables higher performance with fewer drives, while offering the industry's highest reliability. Features Benefits 15K RPM spindle speed   Delivers more I/O's per second than 10K, and faster sustained transfer rates, enabling the same high performance to be met with fewer drives.   Background Media Scan   Proactively scans the media for potential defects during drive idle time without using system bandwidth. It enables incipient errors to be corrected before data is lost.   Enhanced Error Correction Code   Better maintains performance throughout the life of the drive and reduces the probability of lost data.   Fluid Dynamic Bearing Motor   No ball bearings means reduced acoustics and improved reliability.   Full Duty Cycle Reliability   The Cheetah 15K.4 is designed to have the highest reliability, even when in used in demanding applications around the clock, 365 days per year.   Serial Attached SCSI (3 Gb/sec)   Serial Attached SCSI (SAS) enables high-performance 15K SAS drives to interoperate with high-capacity NL35 SATA drives helping simplify and consolidate tiered storage.   Distinctions 30% more IOPS and more than 20% faster response times than 3.5-inch 10K drives The industry's highest reliability, with 1,400,000 hour MTBF

All SAS compatible servers including:
Dell PowerEdge 2900, 2950, 6900, 6950. PowerVault MD1000


Technical Specifications  Description Model number ST373454SS Model Name Cheetah 15K.4 Form Factor(width) 3.5-inch Form Factor(height) 1-inch  Physical Specifications Height 25.4 mm Width 101.6 mm Length 146.05 mm Weight 0.68 kg  Capacity/Interface Formatted Capacity 73.4 Gbytes  Performance   Transfer Rates   Internal Transfer Rate (min) 685 Mbits/sec Internal Transfer Rate (max) 1,142 Mbits/sec Formatted Int Transfer Rate (min) 85.6 MBytes/sec Formatted Int Transfer Rate (max) 142.7 MBytes/sec External (I/O) Transfer Rate (max) 300 MBytes/sec   Seek Times   Average Seek Time, Read 3.5 msec typical Average Seek Time, Write 4 msec typical Track-to-Track Seek, Read 0.2 msec typical Track-to-Track Seek, Write 0.4 msec typical Full Disc Seek, Read 7.4 msec typical Full Disc Seek, Write 7.9 msec typical Average Latency 2 msec   Other   Default Buffer (cache) Size 8,192 Kbytes Spindle Speed 15K RPM Spinup Time 20 sec Power-on to Ready Time 3 sec  Configuration Number of Discs (physical) 4 Number of Heads (physical) 8 Total Cylinders 50,864 Total Tracks 203,456 Bytes Per Sector 512 Track Density (TPI) 85,000 tracks/inch Recording Density (BPI, max) 628,000 bits/inch Bytes/Track (avg) 471,916   Recording Components    Electrical Requirements   Current   Typical Current (12VDC +/- 5%) 0.95 amps Startup Current (12VDC +/- 5%) 2.7 amps Typical Current (5VDC +/- 5%) 1.12 amps Startup Current (5VDC +/- 5%) 1.64 amps   Power   Idle Power (typ) 11.8 watts  Environmental Specifications   Shock and Vibration   Max Operating Shock (2-msec) 65 Gs Max Nonoperating Shock (2-msec) 250 Gs Operating Vibration (max) 0.5 Gs Nonoperating Vibration (max) 2 Gs   Temperature and Humidity   Operating Temperature (max) 55 deg C Operating Temperature (min) 5 deg C Nonoperating Temperature (max) 70 deg C Nonoperating Temperature (min) -40 deg C Operating Temperature Change (max) 20 deg C/hr Nonoperating Temperature Change (max) 20 deg C/hr Operating Humidity (max) 95 percent Nonoperating Humidity (max) 95 percent Operating Humidity Change (max) 20 percent per hour Operating Wet Bulb Temp (max) 28 deg C   Altitude   Operating Altitude (max) 3,048 m Operating Altitude (min) -305 m Nonoperating Altitude (max) 12,210 m Nonoperating Altitude (min) -305 m   Acoustics   Acoustics, Idle (sound power, typ) 3.6 Bels  Reliability MTBF (Hours) 1,400,000 hours Recoverable Read Errors 10 per 1012 bits read Nonrecoverable Read Errors 1 per 1015 bits read Seek Errors 10 per 108 bits read Supports S.M.A.R.T. Yes Service Life 5 year(s) Limited Warranty Period 5 year(s)

Alternate MPNs: J8090 0J8090 0FP548 FP548

Weight: 1.8 lb

Warranty: 1 Year DiscTech

Refurbished

1 Year DiscTech Warranty
