Seagate Part #/MPN: ST9300653SS
DiscTech Item #: SGT-ST9300653SS-FR-1Y
- Factory RefurbishedCondition Levels Explained
The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items.
Product Warranties ExplainedThe product has a manufacturer warranty for the time period specified.
- Warranty:1 Year ManufacturerProduct Warranties Explained
The product has a manufacturer warranty for the time period specified.
- Special Order - Ships in 5-10 business daysSpecial Order - Ships in 5-10 business days
This item has a lead time for fulfilment (as listed), this is approximate. Your credit card will be authorized in full on the day of ordering; it will not be charged until the day of shipment.
Enterprise Grade
Capacity: 300GB
Speed: 15K RPM
Interface Types: SAS
Form Factor: 2.5" SFF Server Drive
Sector Size: 512 / 512e
Sustained Throughput: 202
Average Seek Time: 2.7 / 3.1
Electrical Interface: SAS-2 6Gbps
On-Board Cache: 64MB
Compatible Systems: Dell 10th Gen. 2950 / 6950
Seagate Savvio ST9300653SS 15K.3 300GB 15K 6Gbps SFF Serial SCSI / SAS Hard Drive - Factory Refurbished
The Seagate Savvio 15K.3 drive enables OEMs to build solutions that help data centers process more transactions within a given time frame and meet IT service level agreements. This helps companies increase revenue generation, improve customer satisfaction and complete critical business processes faster while keeping data safe. It also provides the performance benefits needed to entice customers to migrate from legacy, 3.5-inch drives to higher-performing 2.5-inch drives.
Key Features and Benefits
* Doubles Tier 1 data storage capacity (up to 300 GB)
* Provides up to 21% improvement in sequential data read/write performance over prior generation
* Delivers up to 3% faster random read and up to 4% faster random write performance vs. prior generation, and up to 10% faster random read and up to 8% faster random write performance vs. legacy 3.5-inch 15K drives1
* Improves scalability and reliability with 6Gb/s SAS interface support
* Supports Protection Information (PI) to help ensure data is not changed from what the user created—from the moment the data is created throughout the life of the data2
* Improves reliability by up to 20% with an annualized failure rate (AFR) of 0.44%
* Instant Secure Erase™ feature cryptographically erases the data encryption key, thereby helping to protect data should drives be lost, stolen or retired.
* Eases transition from legacy 3.5-inch, 15K drives to next-generation 2.5-in, 15K drives
* Unified Storage architecture minimizes system complexity and reduces operating costs.
* Self-Encrypting Drive (SED) option helps data centers be compliant with corporate and federal data security mandates.3
Compatibility:
All SAS compatible servers including (This list is not all inclusive):
Dell PowerEdge 1900, 1950, 1955, 2900, 2950, 6900, 6950 Servers and MD1120 Storage Arrays.
Compaq/HP Proliant:
BL20p G4, BL460c, BL465c, BL480c, DL360 G4p, DL360 G5, DL380 G4, DL380 G5, DL385, DL385 G2, DL580 G3, DL580 G4, DL585, DL585 G2, ML350 G5, ML370 G4, ML370 G5, ML570 G3, ML570 G4
| Specifications | |
|---|---|
| Model number | ST9300653SS |
| Model Name | Savvio 15K.3 |
| Formatted Capacity | 300 Gbytes |
| Rotational Speed | 15,000 rpm |
| Default Buffer (cache) Size | 64 Mbytes |
| Guaranteed Sectors | 585,937,500 |
| Areal Density (avg) | 448Gb/in2 |
| Performance | |
| External (I/O) Transfer Rate (max) | 600 MBytes/sec |
| Sustained Transfer Rate | 202 MBytes/sec |
| Average Seek Time, Read | 2.7 msec typical |
| Average Seek Time, Write | 3.1 msec typical |
| Average latency | 2.0 msec typical |
| Physical | |
| Form Factor(width) | 2.5-inch |
| Form Factor(height) | .591-inch |
| Height | 15 mm |
| Width | 70.10 mm |
| Length | 100.45mm |
| Weight | 0.200 kg |
| Electrical | |
| Avg. Idle Power | 4.25W |
| Environmental | |
| Max Operating Shock (2-msec) | 40 Gs |
| Max Nonoperating Shock (2-msec) | 300 Gs |
| Operating Vibration (max) | .5 Gs |
| Nonoperating Vibration (max) | 2.4 Gs |
| Operating Temperature (max) | 55 deg C |
| Operating Temperature (min) | 5 deg C |
| Nonoperating Temperature (max) | 70 deg C |
| Nonoperating Temperature (min) | -40 deg C |
| Acoustical | |
| Nonrecoverable Read Errors | 1 per 10^16 bits read |
| Supports S.M.A.R.T. | Yes |
Click here to view the manufacturer's item description/brochure
ROHS Compliant
Weight: 0.5 lb
Warranty: 1 Year Manufacturer
Factory Refurbished
The product has been built, rebuilt or repaired at the original manufacturer's factory (Note we NEVER sell 3rd party repaired items, as we do not find them to be reliable enough). Often these products are extremely close to new in condition, except that they contain at least one recycled or repaired component. Failure rates are often lower on these devices since they have been far more thoroughly tested than new items.
The product has a manufacturer warranty for the time period specified.
1 Year Manufacturer Warranty
The product has a manufacturer warranty for the time period specified.
